Trane R-410A Split System User Manual

Model
SUMMER
Indoor conditions
25ć 30ć 35ć 40ć 45ć 50ć
Total Capacity (Btu/h)
11672 11081 10389 9297 8645 8093
Sensible Capacity (Btu/h)
8287 8072 7762 7117 6779 6496
Input (W)
920 1020 1113 1256 1365 1485
Compressor Frequency (Hz)
74 74 74 74 74 74
Total Capacity (Btu/h)
12548 11948 11184 10437 9706 9034
Sensible Capacity (Btu/h)
9184 8912 8499 8079 7649 7247
Input (W)
928 1031 1126 1263 1374 1510
Compressor Frequency (Hz)
74 74 74 74 74 74
Total Capacity (Btu/h)
13347 12927 11600 11269 10665 9594
Sensible Capacity (Btu/h)
9727 9590 8792 8662 8338 7629
Input (W)
929 1036 1130 1257 1388 1503
Compressor Frequency (Hz)
74 74 74 74 74 74
Total Capacity (Btu/h)
13753 13688 13408 13006 12815 12020
Sensible Capacity (Btu/h)
9352 9689 9867 9935 10150 9857
Input (W)
1032 1128 1206 1359 1445 1570
Compressor Frequency (Hz)
74 74 74 74 74 74
WINTER
12ć D7ć D4ć D0ć D-4ć D-7ć D
11ć W6ć W3ć W-1ć W-6ć W-8ć W
Total Capacity (Btu/h)
14609.8 13077 11456 12575 11483 10785
Input (W)
922 915 908 1271 1300 1347
Compressor Frequency (Hz)
68 68 68 68 68 68
Total Capacity (Btu/h)
13932 12421 11154 12130 11266 10613
Input (W)
941 930 915 1322 1383 1426
Compressor Frequency (Hz)
68 68 68 68 68 68
Total Capacity (Btu/h)
13721 12200 10921 11961 11121 10519
Input (W)
958 940 920 1335 1379 1456
Compressor Frequency (Hz)
68 68 68 68 68 68
Total Capacity (Btu/h)
13237 11728 10468 11251 10827 10344
Input (W)
962 952 937 1374 1397 1499
Compressor Frequency (Hz)
68 68 68 68 68 68
15ć
18
ć
20ć
22ć
27ć D 19ć W
32ć D 23ć W
OUTDOOR TEMPERATURE DRY
Indoor conditions
4MYW5512A1/4TYK5512A1
4MXW5512A1/4TXK5512A1
OUTDOOR TEMPERATURE DRY
21ć D 15ć W
24ć D 17ć W
22

Trane R-410A Split System Specifications

General

Brand	Trane
Model	R-410A Split System
Category	Air Conditioner
Language	English
