Trane R-410A Split System User Manual

Model
SUMMER
Indoor conditions
25ć 30ć 35ć 40ć 45ć 50ć
Total Capacity (Btu/h)
20474 19611 18460 17180 15832 13480
Sensible Capacity (Btu/h)
14948 14610 14030 13316 12507 10852
Input (W)
1541 1774 1915 2041 2170 2031
Compressor Frequency (Hz)
84 84 84 84 84 84
Total Capacity (Btu/h)
22359 20915 19839 18494 17068 14862
Sensible Capacity (Btu/h)
16211 15289 14620 13743 12784 11220
Input (W)
1570 1786 1951 2073 2202 2042
Compressor Frequency (Hz)
84 84 84 84 84 84
Total Capacity (Btu/h)
23560 22898 22007 20474 18935 15733
Sensible Capacity (Btu/h)
17293 16989 16515 15518 14504 12176
Input (W)
1595 1814 1985 2108 2240 2063
Compressor Frequency (Hz)
84 84 84 84 84 84
Total Capacity (Btu/h)
24325 24598 24195 23557 22468 19375
Sensible Capacity (Btu/h)
17027 17586 17662 17549 17074 15016
Input (W)
1616 1836 2015 2163 2313 2176
Compressor Frequency (Hz)
84 84 84 84 84 84
WINTER
12ć D7ć D4ć D0ć D-4ć D-7ć D
11ć W6ć W3ć W-1ć W-6ć W-8ć W
Total Capacity (Btu/h)
26192 24721 22585 19201 17463 16902
Input (W)
1995 1871 1778 1707 1655 1561
Compressor Frequency (Hz)
100 100 100 100 100 100
Total Capacity (Btu/h)
25542 24184 22637 19100 17282 17089
Input (W)
2004 1900 1794 1718 1652 1578
Compressor Frequency (Hz)
100 100 100 100 100 100
Total Capacity (Btu/h)
25334 23884 22367 18864 17068 16881
Input (W)
2024 1930 1827 1741 1660 1618
Compressor Frequency (Hz)
100 100 100 100 100 100
Total Capacity (Btu/h)
24046 23697 21625 17987 16841 16473
Input (W)
1993 1918 1873 1776 1696 1625
Compressor Frequency (Hz)
100 100 100 100 100 100
15ć
18
ć
20ć
22ć
27ć D 19ć W
32ć D 23ć W
OUTDOOR TEMPERATURE DRY
Indoor conditions
4MYW5524AB/4TYK5524AB
4MXW5524AB/4TXK5524AB
OUTDOOR TEMPERATURE DRY
21ć D 15ć W
24ć D 17ć W
27
