Diagnostics
150 RTAC-SVX01J-EN
Power Loss -
Compressor 1A
Cprsr Immediate NonLatch
All
compressor
running
modes
[all
compressor
starting and
non-running
modes]
The compressor had previously established currents while
running and then all three phases of current were lost. Design:
Less than 10% RLA, trip in 2.64 seconds. This diagnostic will
preclude the Phase Loss Diagnostic and the Transition Complete
Input Opened Diagnostic from being called out. To prevent this
diagnostic from occurring with the intended disconnect of main
power, the minimum time to trip must be greater than the
guaranteed reset time of the Starter module. Note: This
diagnostic prevents nuisance latching diagnostics due to a
momentary power loss - It does not protect motor/compressor
from uncontrolled power reapplication. See Momentary Power
Loss Diagnostic for this protection. This diagnostic is not active
during the start mode before the transition complete input is
proven. Thus a random power loss during a start would result in
either a "Starter Fault Type 3" or a "Starter Did Not Transition"
latching diagnostic.
Remote
Power Loss -
Compressor 1B
Cprsr Immediate NonLatch
All
compressor
running
modes
[all
compressor
starting and
non-running
modes]
The compressor had previously established currents while
running and then all three phases of current were lost. Design:
Less than 10% RLA, trip in 2.64 seconds. This diagnostic will
preclude the Phase Loss Diagnostic and the Transition Complete
Input Opened Diagnostic from being called out. To prevent this
diagnostic from occurring with the intended disconnect of main
power, the minimum time to trip must be greater than the
guaranteed reset time of the Starter module.
Remote
Power Loss -
Compressor 2A
Cprsr Immediate NonLatch
All
compressor
running
modes
[all
compressor
starting and
non-running
modes]
The compressor had previously established currents while
running and then all three phases of current were lost. Design:
Less than 10% RLA, trip in 2.64 seconds. This diagnostic will
preclude the Phase Loss Diagnostic and the Transition Complete
Input Opened Diagnostic from being called out. To prevent this
diagnostic from occurring with the intended disconnect of main
power, the minimum time to trip must be greater than the
guaranteed reset time of the Starter module.
Remote
Power Loss -
Compressor 2B
Cprsr Immediate NonLatch
All
compressor
running
modes
[all
compressor
starting and
non-running
modes]
The compressor had previously established currents while
running and then all three phases of current were lost. Design:
Less than 10% RLA, trip in 2.64 seconds. This diagnostic will
preclude the Phase Loss Diagnostic and the Transition Complete
Input Opened Diagnostic from being called out. To prevent this
diagnostic from occurring with the intended disconnect of main
power, the minimum time to trip must be greater than the
guaranteed reset time of the Starter module.
Remote
Severe Current
Imbalance -
Compressor 1A
Circuit Immediate Latch
All Running
Modes
A 30% Current Imbalance has been detected on one phase
relative to the average of all 3 phases for 90 continuous seconds.
Local
Severe Current
Imbalance -
Compressor 1B
Circuit Immediate Latch
All Running
Modes
A 30% Current Imbalance has been detected on one phase
relative to the average of all 3 phases for 90 continuous seconds.
Local
Severe Current
Imbalance -
Compressor 2A
Circuit Immediate Latch
All Running
Modes
A 30% Current Imbalance has been detected on one phase
relative to the average of all 3 phases for 90 continuous seconds
Local
Severe Current
Imbalance -
Compressor 2B
Circuit Immediate Latch
All Running
Modes
A 30% Current Imbalance has been detected on one phase
relative to the average of all 3 phases for 90 continuous seconds.
Local
Starter 1A Dry Run
Test
Cprsr Immediate Latch
Starter Dry
Run Mode
While in the Starter Dry Run Mode either 50 % Line Voltage was
sensed at the Potential Transformers or 10 % RLA Current was
sensed at the Current Transformers.
Local
Starter 1B Dry Run
Test
Cprsr Immediate Latch
Starter Dry
Run Mode
While in the Starter Dry Run Mode either 50 % Line Voltage was
sensed at the Potential Transformers or 10 % RLA Current was
sensed at the Current Transformers.
Local
Starter 2A Dry Run
Test
Cprsr Immediate Latch
Starter Dry
Run Mode
While in the Starter Dry Run Mode either 50 % Line Voltage was
sensed at the Potential Transformers or 10 % RLA Current was
sensed at the Current Transformers.
Local
Starter 2B Dry Run
Test
Cprsr Immediate Latch
Starter Dry
Run Mode
While in the Starter Dry Run Mode either 50 % Line Voltage was
sensed at the Potential Transformers or 10 % RLA Current was
sensed at the Current Transformers.
Local
Table 66. Starter diagnostics (continued)
Diagnostic Name
and Source
Affects
Target Severity Persistence
Active
Modes
[Inactive
Modes] Criteria
Reset
Level
