Trane R Series Installation, Operation And Maintenance

Diagnostics
RTAC-SVX01J-EN 153
Transition Complete
Input Opened -
Compressor 1A
Cprsr Immediate Latch
All running
modes
The Transition Complete input was found to be opened with the
compressor motor running after a successful completion of
transition. This is active only for Y-Delta, Auto-Transformer,
Primary Reactor, and X-Line Starters. To prevent this diagnostic
from occurring as the result of a power loss to the contactors, the
minimum time to trip must be greater than the trip time for the
power loss diagnostic.
Local
Transition Complete
Input Opened -
Compressor 1B
Cprsr Immediate Latch
All running
modes
The Transition Complete input was found to be opened with the
compressor motor running after a successful completion of
transition. This is active only for Y-Delta, Auto-Transformer,
Primary Reactor, and X-Line Starters. To prevent this diagnostic
from occurring as the result of a power loss to the contactors, the
minimum time to trip must be greater than the trip time for the
power loss diagnostic.
Local
Transition Complete
Input Opened -
Compressor 2A
Cprsr Immediate Latch
All running
modes
The Transition Complete input was found to be opened with the
compressor motor running after a successful completion of
transition. This is active only for Y-Delta, Auto-Transformer,
Primary Reactor, and X-Line Starters. To prevent this diagnostic
from occurring as the result of a power loss to the contactors, the
minimum time to trip must be greater than the trip time for the
power loss diagnostic.
Local
Transition Complete
Input Opened -
Compressor 2B
Cprsr Immediate Latch
All running
modes
The Transition Complete input was found to be opened with the
compressor motor running after a successful completion of
transition. This is active only for Y-Delta, Auto-Transformer,
Primary Reactor, and X-Line Starters. To prevent this diagnostic
from occurring as the result of a power loss to the contactors, the
minimum time to trip must be greater than the trip time for the
power loss diagnostic.
Local
Transition Complete
Input Shorted -
Compressor 1A
Cprsr Immediate Latch Pre-Start
The Transition Complete input was found to be shorted before the
compressor was started. This is active for all electromechanical
starters.
Local
Transition Complete
Input Shorted -
Compressor 1B
Cprsr Immediate Latch Pre-Start
The Transition Complete input was found to be shorted before the
compressor was started. This is active for all electromechanical
starters.
Local
Transition Complete
Input Shorted -
Compressor 2A
Cprsr Immediate Latch Pre-Start
The Transition Complete input was found to be shorted before the
compressor was started. This is active for all electromechanical
starters.
Local
Transition Complete
Input Shorted -
Compressor 2B
Cprsr Immediate Latch Pre-Start
The Transition Complete input was found to be shorted before the
compressor was started. This is active for all electromechanical
starters.
Local
Under Voltage Chiller Normal NonLatch
Pre-Start and
Any Ckt(s)
Energzd
Nom. trip: 60 seconds at less than 87.5%, 2.8% at 200V 1.8%
at 575V, Auto Reset at 90% or greater.
Remote
Table 66. Starter diagnostics (continued)
Diagnostic Name
and Source
Affects
Target Severity Persistence
Active
Modes
[Inactive
Modes] Criteria
Reset
Level
