Diagnostics
160 RTAC-SVX01J-EN
Oil Flow Fault -
Compressor 1B
Circuit Immediate Latch
Starter Contactor
Energized
[all Stop modes]
The Intermediate Oil Pressure Transducer for this cprsr is
reading a pressure either above its respective circuit's
Condenser Pressure by 15 Psia or more, , or below its respective
Suction Pressure 10 Psia or more for 30 seconds continuously.
Local
Oil Flow Fault -
Compressor 2A
Circuit Immediate Latch
Starter Contactor
Energized
[all Stop modes]
The Intermediate Oil Pressure Transducer for this cprsr is
reading a pressure either above its respective circuit's
Condenser Pressure by 15 Psia or more, , or below its respective
Suction Pressure 10 Psia or more for 30 seconds continuously.
Local
Oil Flow Fault -
Compressor 2B
Circuit Immediate Latch
Starter Contactor
Energized
[all Stop modes]
The Intermediate Oil Pressure Transducer for this cprsr is
reading a pressure either above its respective circuit's
Condenser Pressure by 15 Psia or more, , or below its respective
Suction Pressure 10 Psia or more for 30 seconds continuously.
Local
Oil Temperature
Sensor - Cprsr 1B
Circuit Normal Latch All Bad Sensor or LLID Remote
Oil Temperature
Sensor - Cprsr 2B
Circuit Normal Latch All Bad Sensor or LLID Remote
Oil Temperature
Sensor -Cprsr 1A
Circuit Normal Latch All Bad Sensor or LLID Remote
Oil Temperature
Sensor -Cprsr 2A
Circuit Normal Latch All Bad Sensor or LLID Remote
Outdoor Air
Temperature Sensor
Chiller Normal Latch All
Bad Sensor or LLID. Note that if this diagnostic occurs,
operational pumpdown will be performed regardless of the last
valid temperature
Remote
Pumpdown
Terminated - Circuit
1
None Info NonLatch Pumpdown Mode
The pumpdown cycle for this circuit was terminated abnormally
due to excessive time or due to a specific set of diagnostic
criteria - but w/o associated latching diagnostics
Remote
Pumpdown
Terminated - Circuit
2
None Info NonLatch Pumpdown Mode
The pumpdown cycle for this circuit was terminated abnormally
due to excessive time or due to a specific set of diagnostic
criteria - but w/o associated latching diagnostics
Remote
Software Error
1001: Call Trane
Service (beginning
with Rev 29)
All
Reported if a compressor is found to be running without chilled
water flow for three minutes. Previously, this error would be
identified after five minutes.
Software Error
1002: Call Trane
Service (beginning
with Rev 29)
All
Reported if state chart misalignment in stopped or inactive state
occurs.
Software Error
1003: Call Trane
Service (beginning
with Rev 29)
All Reported if state chart misalignment in stopping state occurs.
Software Error
Number: 1001 (Rev
28)
All
functions
Immediate
Latch -
power
down
reset is
reqd
All
A high level software watchdog has detected a condition in which
there was a continuous 5 minute period of compressor
operation, with neither chilled water flow nor a" contactor
interrupt failure" diagnostic active. The occurrence of this
software error message suggests an internal software state
chart misalignment has occurred. The events that led up to this
failure, if known, should be recorded and transmitted to Trane
Controls Engineering - (SW rev 24 and higher)
Starter Failed to
Arm/Start - Cprsr 1A
Cprsr Info Latch All
Starter failed to arm or start within the allotted time (15
seconds).
Local
Starter Failed to
Arm/Start - Cprsr 1B
Cprsr Info Latch All
Starter failed to arm or start within the allotted time (15
seconds).
Local
Starter Failed to
Arm/Start - Cprsr 2A
Cprsr Info Latch All
Starter failed to arm or start within the allotted time (15
seconds).
Local
Starter Failed to
Arm/Start - Cprsr 2B
Cprsr Info Latch All
Starter failed to arm or start within the allotted time (15
seconds).
Local
Starter Module
Memory Error Type 1
- Starter 2A
None Info Latch All
Checksum on RAM copy of the Starter LLID configuration failed.
Configuration recalled from EEPROM.
Local
Starter Module
Memory Error Type 1
- Starter 2B
None Info Latch All
Checksum on RAM copy of the Starter LLID configuration failed.
Configuration recalled from EEPROM.
Local
Table 67. Main processor diagnostics (continued)
Diagnostic Name
Affects
Target Severity
Persist-
ence
Active Modes
[Inactive
Modes] Criteria
Reset
Level
