Trane R Series Installation, Operation And Maintenance

Dimensions and Weights
40 RTAC-SVX01J-EN
Table 16. Weights - remote - 60 Hz - aluminum or CompleteCoat coils
Unit
Size
(tons)
Standard Efficiency High Efficiency
Shipping Operating Shipping Operating
lb kg lb kg lb kg lb kg
140
8358 3791 8584 3894 8291 3761 8604 3903
155
8299 3765 8599 3901 9497 4308 9868 4476
170
8305 3767 8615 3908 9503 4311 9933 4506
185
9860 4472 10230 4640 11059 5016 11499 5216
200
10217 4634 10646 4829 11417 5179 11865 5382
225
11514 5223 11954 5423 ----
250
11613 5268 12061 5471 ----
1. Operating weight includes refrigerant and water.
2. Shipping weight includes nitrogen holding charge.
3. All weights +/- 3%.
Table 17. Weights - remote - 60 Hz - copper coils
Nominal
Tonnage
Standard Efficiency High Efficiency
Shipping
Weight (lb)
Shipping
Weight (kg)
Operating
Weight (lb)
Operating
Weight (kg)
Shipping
Weight (lb)
Shipping
Weight (kg)
Operating
Weight (lb)
Operating
Weight (kg)
140
10955 4969 11158 5061 10750 4876 11179 5071
155
10873 4932 11174 5069 12916 5859 13285 6026
170
10878 4934 11189 5075 13452 6102 13354 6057
185
13609 6173 13649 6191 15325 6951 15764 7150
200
13666 6199 14066 6380 15681 7113 16129 7316
225
15780 7158 16217 7356 ----
250
15878 7202 16325 7405 ----
1. Operating weight includes refrigerant and water.
2. Shipping weight includes nitrogen holding charge.
3. All weights +/- 3%.
Table 18. Weights - remote evaporator - 60 Hz
Nominal
Tonnage
Standard Efficiency High Efficiency
Shipping
Weight (lb)
Shipping
Weight (kg)
Operating
Weight (lb)
Operating
Weight (kg)
Shipping
Weight (lb)
Shipping
Weight (kg)
Operating
Weight (lb)
Operating
Weight (kg)
140
2486 1128 2730 1238 2528 1147 2805 1272
155
2525 1145 2790 1266 2556 1159 2850 1293
170
2528 1147 2805 1272 2600 1179 2920 1325
185
2556 1159 2850 1293 2797 1269 3114 1413
200
2600 1179 2920 1325 2846 1291 3192 1448
225
2797 1269 3114 1413 ----
250
2846 1291 3192 1448 ----
1. Operating weight includes refrigerant and water.
2. Shipping weight includes nitrogen holding charge.
3. All weights +/- 3%.
