Trane R Series Installation, Operation And Maintenance

Installation - Mechanical
RTAC-SVX01J-EN 51
Figure 20. Evaporator water pressure drop — 3-pass evaporator — 140-250T
Figure 21. Evaporator water pressure drop — 3-pass evaporator — 250-500T
1.00
10.00
100.00
100
140S, 120H(50Hz)
155S, 130H(50Hz)
170S, 140H
185S, 155H
200S, 170H
225S, 185H
250S(60Hz), 200H,
225H, 250H(60Hz)
Pressure Drop (ft H2O)
Flow Rate (GPM)
200 300 400 500 600 700
5.00
50.00
1.00
10.00
100 1000
250S(50Hz)
275S
300S, 250H(50Hz)
350S(60Hz), 275H, 300H
350S(50Hz)
400S, 350H
375S(50Hz)
450S(60Hz), 375H(50Hz)
500S(60Hz), 400H
Pressure Drop (ft H2O)
Flow Rate (GPM)
200 300 400 500 600 800 1200
80.00
20.00
40.00
60.00
5.00
