Trane R Series

Installation - Electrical
RTAC-SVX01J-EN 69
500
200/60/3 1 n/a
200/60/3 2 4 14/14 1.5 6.5 7.3 1.59
459-459/
459-459
2525-2525/
2525-2525
821-821/
821-821
1130/1130 1200/1200
230/60/3 1 n/a
230/60/3 2 4 14/14 1.5 6.5 7.3 1.59
399-399/
399-399
2126-2126/
2126-2126
691-691/
691-691
994/994 1200/1200
380/60/3 1 n/a
380/60/3 2 4 14/14 1.5 3.5 3.7 1.59
242-242/
242-242
1306-1306/
1306-1306
424-424/
424-424
596/596 800/800
460/60/3 1 4 28 1.5 3 3.7 1.59
200-200/
200-200
1065-1065/
1065-1065
346-346/
346-346
940 1000
460/60/3 2 4 14/14 1.5 3 3.7 1.59
200-200/
200-200
1065-1065/
1065-1065
346-346/
346-346
495/495 600/600
575/60/3 1 4 28 1.5 2.5 3.7 1.59
160-160/
160-160
853-853/853-
853
277-277/
277-277
758 800
575/60/3 2 4 14/14 1.5 2.5 3.7 1.59
160-160/
160-160
853-853/853-
853
277-277/
277-277
399/399 500/500
Notes:
1. Voltage Utilization Range: +/- 10% of rated voltage. Rated voltage (use range): 200/60/3 (180-220), 230/60/3 (208-254), 380/60/3 (342-418), 460/
60/3 (414-506), 575/60/3 (516-633)
2. As standard, 140-250 ton (60 Hz) units and 140-200 ton (50Hz) units have a single point power connection. Optional dual point power connections are
available. As standard, 275-500 ton (60Hz) units and 250-400 ton (50Hz) units have dual point power connections. Optional single point power
connections are available on 460V and 575V/60 Hz and 400V/50 Hz units.
3. Control VA includes operational controls only. It does not include evaporator heaters.
4. RLA - Rated Load Amps
5. XLRA - Locked Rotor Amps - based on full winding (x-line) start units). YLRA for wye-delta starters is ~1/3 of LRA of x-line units.
6. MCA - Minimum Circuit Ampacity - 125 percent of largest compressor RLA plus 100 percent of all other loads.
7. Max fuse or MOPD = 225 percent of the largest compressor RLA plus 100 percent of the second compressor RLA, plus the sum of the condenser fan
FLA. (Use FLA per circuit, NOT FLA for the entire unit).
8. A separate 115/60/1, 20 amp or 220/50/1, 15 amp customer provided power connection is required to power the evaporator heaters (1640 watts).
9. Local codes may take precedence.
Table 35. Standard efficiency - all ambient options (continued)
Unit
Size
Rated
Voltage
1
# Pwr
Conn
2
#
Comp
# Fan
Ckt1/
Ckt2
Fan
kW
Fan
FLA
VFD
Input
Cntrl
VA
3
RLA
4
Ckt1/Ckt2
XLRA
5
Ckt1/Ckt2
YLRA
5
Ckt1/Ckt2
MCA
6
Ckt1/
Ckt2
MOP
7
Ckt1/
Ckt2
