Installation - Electrical
RTAC-SVX01J-EN 71
185
200/60/3 1 2 13 1.5 6.5 7.3 0.83 373-305 2525/2156 821/701 861 1200
200/60/3 2 2 7/6 1.5 6.5 7.3 0.83 373/305 2525/2156 821/701 517/421 800/700
230/60/3 1 2 13 1.5 6.5 7.3 0.83 324-265 2126/1756 691/571 760 1000
230/60/3 2 2 7/6 1.5 6.5 7.3 0.83 324/265 2126/1756 691/571 455/371 700/600
380/60/3 1 2 13 1.5 3.5 3.7 0.83 196-161 1306/1060 424/345 454 600
380/60/3 2 2 7/6 1.5 3.5 3.7 0.83 196/161 1306/1060 424/345 272/222 450/350
460/60/3 1 2 13 1.5 3 3.7 0.83 162-133 1065/878 346/285 378 500
460/60/3 2 2 7/6 1.5 3 3.7 0.83 162/133 1065/878 346/285 226/185 350/300
575/60/3 1 2 13 1.5 2.5 3.7 0.83 130-106 853/705 277/229 305 400
575/60/3 2 2 7/6 1.5 2.5 3.7 0.83 130/106 853/705 277/229 183/149 300/250
400/50/3 1 2 13 1.5 2.8 3.7 0.83 189-160 1089/1089 354/354 437 600
400/50/3 2 2 7/6 1.5 2.8 3.7 0.83 189/160 1089/1089 354/354 259/218 400/350
200
200/60/3 1 2 14 1.5 6.5 7.3 0.83 373/373 2525/2525 821/821 936 1200
200/60/3 2 2 7/7 1.5 6.5 7.3 0.83 373/373 2525/2525 821/821 517/513 800/800
230/60/3 1 2 14 1.5 6.5 7.3 0.83 324/324 2126/2126 691/691 825 1000
230/60/3 2 2 7/7 1.5 6.5 7.3 0.83 324/324 2126/2126 691/691 455/451 700/700
380/60/3 1 2 14 1.5 3.5 3.7 0.83 196/196 1306/1306 424/424 493 600
380/60/3 2 2 7/7 1.5 3.5 3.7 0.83 196/196 1306/1306 424/424 272/270 450/450
460/60/3 1 2 14 1.5 3 3.7 0.83 162/162 1065/1065 346/346 410 500
460/60/3 2 2 7/7 1.5 3 3.7 0.83 162/162 1065/1065 346/346 226/224 350/350
575/60/3 1 2 14 1.5 2.5 3.7 0.83 130/130 853/853 277/277 331 450
575/60/3 2 2 7/7 1.5 2.5 3.7 0.83 130/130 853/853 277/277 183/181 300/300
400/50/3 1 2 14 1.5 2.8 3.7 0.83 189/189 1089/1089 354/354 468 600
400/50/3 2 2 7/7 1.5 2.8 3.7 0.83 189/189 1089/1089 354/354 259/257 400/400
225
200/60/3 1 2 14 1.5 6.5 7.3 0.83 447/373 2525/2525 821/821 1028 1200
200/60/3 2 2 8/6 1.5 6.5 7.3 0.83 447/373 2525/2525 821/821 616/506 1000/800
230/60/3 1 2 14 1.5 6.5 7.3 0.83 388/324 2126/2126 691/691 905 1200
230/60/3 2 2 8/6 1.5 6.5 7.3 0.83 388/324 2126/2126 691/691 541/445 800/700
380/60/3 1 2 14 1.5 3.5 3.7 0.83 235/196 1306/1306 424/424 541 700
380/60/3 2 2 8/6 1.5 3.5 3.7 0.83 235/196 1306/1306 424/424 324/266 500/450
460/60/3 1 2 14 1.5 3 3.7 0.83 194/162 1065/1065 346/346 450 600
460/60/3 2 2 8/6 1.5 3 3.7 0.83 194/162 1065/1065 346/346 269/221 450/350
575/60/3 1 2 14 1.5 2.5 3.7 0.83 155/130 853/853 277/277 363 500
575/60/3 2 2 8/6 1.5 2.5 3.7 0.83 155/130 853/853 277/277 216/179 350/300
250
200/60/3 1 2 16 1.5 6.5 7.3 0.83 447/447 2525/2525 821/821 1115 1200
200/60/3 2 2 8/8 1.5 6.5 7.3 0.83 447/447 2525/2525 821/821 616/612 1000/1000
230/60/3 1 2 16 1.5 6.5 7.3 0.83 388/388 2126/2126 691/691 982 1200
230/60/3 2 2 8/8 1.5 6.5 7.3 0.83 388/388 2126/2126 691/691 541/538 800/800
380/60/3 1 2 16 1.5 3.5 3.7 0.83 235/235 1306/1306 424/424 587 800
380/60/3 2 2 8/8 1.5 3.5 3.7 0.83 235/235 1306/1306 424/424 324/322 500/500
460/60/3 1 2 16 1.5 3 3.7 0.83 194/194 1065/1065 346/346 488 600
460/60/3 2 2 8/8 1.5 3 3.7 0.83 194/194 1065/1065 346/346 269/267 450/450
575/60/3 1 2 7/4 1.5 2.5 3.7 0.83 155/155 853/853 277/277 393 500
575/60/3 2 2 8/8 1.5 2.5 3.7 0.83 155/155 853/853 277/277 216/215 350/350
400/50/3 1 3 16 1.5 2.8 3.7 1.2 132-132/189 896-896/1089 291-291/354 552 700
400/50/3 2 3 10/6 1.5 2.8 3.7 1.2 132-132/189 896-896/1089 291-291/354 329/256 450/400
Table 36. High efficiency - standard and low ambient options (continued)
Unit
Size
Rated
Voltage
1
#
Power
Conn
2
#
Comp
# Fan
Ckt1/
Ckt2
Fan
kW
Fan
FLA
VFD
Input
Cntrl
VA
3
RLA
4
Ckt1/Ckt2
XLRA
5
Ckt1/Ckt2
YLRA
5
Ckt1/Ckt2
MCA
6
Ckt1/
Ckt2
MOP
7
Ckt1/
Ckt2
