Trane R Series

Installation - Electrical
RTAC-SVX01J-EN 73
400
200/60/3 1 n/a
200/60/3 2 4 14/14 1.5 6.5 7.3 1.59
373-373/
373-373
2525-2525/
2525-2525
821-821/
821-821
936/936 1200/1200
230/60/3 1 n/a
230/60/3 2 4 14/14 1.5 6.5 7.3 1.59
324-324/
324-324
2126-2126/
2126-2126
691-691/
691-691
825/825 1000/1000
380/60/3 1 n/a
380/60/3 2 4 14/14 1.5 3.5 3.7 1.59
196-196/
196-196
1306-1306/
1306-1306
424-424/
424-424
493/493 600/600
460/60/3 1 4 28 1.5 3 3.7 1.59
162-162/162-
162
1065-1065/
1065-1065
346-346/
346-346
779 900
460/60/3 2 4 14/14 1.5 3 3.7 1.59
162-162/
162-162
1065-1065/
1065-1065
346-346/3
46-346
410/410 500/500
575/60/3 1 4 28 1.5 2.5 3.7 1.59
130-130/
130-130
853-853/
853-853
277-277/
277-277
630 700
575/60/3 2 4 14/14 1.5 2.5 3.7 1.59
130-130/
130-130
853-853/
853-853
277-277/
277-277
331/331 450/450
400/50/3 1 4 28 1.5 2.8 3.7 1.59
189-189/
189-189
1089-1089/
1089-1089
354-354/
354-354
889 1000
400/50/3 2 4 14/14 1.5 2.8 3.7 1.59
189-189/
189-189
1089-1089/
1089-1089
354-354/
354-354
468/468 600/600
Notes:
1. Voltage Utilization Range: +/- 10% of rated voltage. Rated voltage (use range): 200/60/3 (180-220), 230/60/3 (208-254), 380/60/3 (342-418), 460/
60/3 (414-506), 575/60/3 (516-633)
2. As standard, 140-250 ton (60 Hz) units and 140-200 ton (50Hz) units have a single point power connection. Optional dual point power connections are
available. As standard, 275-500 ton (60Hz) units and 250-400 ton (50Hz) units have dual point power connections. Optional single point power
connections are available on 460V and 575V/60 Hz and 400V/50 Hz units.
3. Control VA includes operational controls only. It does not include evaporator heaters.
4. RLA - Rated Load Amps
5. XLRA - Locked Rotor Amps - based on full winding (x-line) start units). YLRA for wye-delta starters is ~1/3 of LRA of x-line units.
6. MCA - Minimum Circuit Ampacity - 125 percent of largest compressor RLA plus 100 percent of all other loads.
7. Max fuse or MOPD = 225 percent of the largest compressor RLA plus 100 percent of the second compressor RLA, plus the sum of the condenser fan FLA.
(Use FLA per circuit, NOT FLA for the entire unit).
8. A separate 115/60/1, 20 amp or 220/50/1, 15 amp customer provided power connection is required to power the evaporator heaters (1640 watts).
9. Local codes may take precedence.
Table 36. High efficiency - standard and low ambient options (continued)
Unit
Size
Rated
Voltage
1
#
Power
Conn
2
#
Comp
# Fan
Ckt1/
Ckt2
Fan
kW
Fan
FLA
VFD
Input
Cntrl
VA
3
RLA
4
Ckt1/Ckt2
XLRA
5
Ckt1/Ckt2
YLRA
5
Ckt1/Ckt2
MCA
6
Ckt1/
Ckt2
MOP
7
Ckt1/
Ckt2
Table 37. High efficiency - high and wide ambient options
Unit
Size
Rated
Voltage
1
#
Power
Conn
2
#
Comp
# Fan
Ckt1/
Ckt2
Fan
kW
Fan
FLA
VFD
Input
Cntrl
VA
3
RLA
4
Ckt1/Ckt2
XLRA
5
Ckt1/Ckt2
YLRA
5
Ckt1/Ckt2
MCA
6
Ckt1/
Ckt2
MOP
7
Ckt1/
Ckt2
120
400/50/3 1 2 8 1.5 2.8 3.7 0.83 118/118 796/796 259/259 292 400
400/50/3 2 2 4/4 1.5 2.8 3.7 0.83 118/118 796/796 259/259 162/160 250/250
130
400/50/3 1 2 9 1.5 2.8 3.7 0.83 138/118 896/796 291/259 320 450
400/50/3 2 2 5/4 1.5 2.8 3.7 0.83 138/118 896/796 291/259 189/160 300/250
140
200/60/3 1 2 10 1.5 6.5 7.3 0.83 270/270 1845/1845 600/600 678 800
200/60/3 2 2 5/5 1.5 6.5 7.3 0.83 270/270 1845/1845 600/600 375/371 600/600
230/60/3 1 2 10 1.5 6.5 7.3 0.83 235/235 1556/1556 506/506 599 800
230/60/3 2 2 5/5 1.5 6.5 7.3 0.83 235/235 1556/1556 506/506 331/327 500/500
380/60/3 1 2 10 1.5 3.5 3.7 0.83 142/142 973/973 316/316 357 450
380/60/3 2 2 5/5 1.5 3.5 3.7 0.83 142/142 973/973 316/316 197/195 300/300
460/60/3 1 2 10 1.5 3 3.7 0.83 118/118 774/774 252/252 299 400
460/60/3 2 2 5/5 1.5 3 3.7 0.83 118/118 774/774 252/252 165/163 250/250
575/60/3 1 2 10 1.5 2.5 3.7 0.83 94/94 631/631 205/205 240 300
575/60/3 2 2 5/5 1.5 2.5 3.7 0.83 94/94 631/631 205/205 133/131 225/225
400/50/3 1 2 10 1.5 2.8 3.7 0.83 138/138 896/896 291/291 342 450
400/50/3 2 2 5/5 1.5 2.8 3.7 0.83 138/138 896/896 291/291 189/187 300/300
