Trane R Series - Optional Bidirectional Communications Link (BCL)

Installation - Electrical
RTAC-SVX01J-EN 75
225
200/60/3 1 2 14 1.5 6.5 7.3 0.83 459/386 2525/2525 821/821 1056 1200
200/60/3 2 2 8/6 1.5 6.5 7.3 0.83 459/386 2525/2525 821/821 631/522 1000/800
230/60/3 1 2 14 1.5 6.5 7.3 0.83 399/336 2126/2126 691/691 931 1200
230/60/3 2 2 8/6 1.5 6.5 7.3 0.83 399/336 2126/2126 691/691 555/460 800/700
380/60/3 1 2 14 1.5 3.5 3.7 0.83 242/203 1306/1306 424/424 557 700
380/60/3 2 2 8/6 1.5 3.5 3.7 0.83 242/203 1306/1306 424/424 333/275 500/450
460/60/3 1 2 14 1.5 3 3.7 0.83 200/168 1065/1065 346/346 463 600
460/60/3 2 2 8/6 1.5 3 3.7 0.83 200/168 1065/1065 346/346 276/229 450/350
575/60/3 1 2 14 1.5 2.5 3.7 0.83 160/134 853/853 277/277 373 500
575/60/3 2 2 8/6 1.5 2.5 3.7 0.83 160/134 853/853 277/277 223/184 350/300
250
200/60/3 1 2 16 1.5 6.5 7.3 0.83 459/459 2525/2525 821/821 1142 1200
200/60/3 2 2 8/8 1.5 6.5 7.3 0.83 459/459 2525/2525 821/821 631/627 1000/1000
230/60/3 1 2 16 1.5 6.5 7.3 0.83 399/399 2126/2126 691/691 1007 1200
230/60/3 2 2 8/8 1.5 6.5 7.3 0.83 399/399 2126/2126 691/691 555/552 800/800
380/60/3 1 2 16 1.5 3.5 3.7 0.83 242/242 1306/1306 424/424 603 800
380/60/3 2 2 8/8 1.5 3.5 3.7 0.83 242/242 1306/1306 424/424 333/331 500/500
460/60/3 1 2 16 1.5 3 3.7 0.83 200/200 1065/1065 346/346 501 700
460/60/3 2 2 8/8 1.5 3 3.7 0.83 200/200 1065/1065 346/346 276/275 450/450
575/60/3 1 2 16 1.5 2.5 3.7 0.83 160/160 853/853 277/277 404 500
575/60/3 2 2 8/8 1.5 2.5 3.7 0.83 160/160 853/853 277/277 223/221 350/350
400/50/3 1 3 16 1.5 2.8 3.7 1.2 138-138/198 896-896/1089 291-291/354 575 700
400/50/3 2 3 10/6 1.5 2.8 3.7 1.2 138-138/198 896-896/1089 291-291/354 342/267 450/450
275
200/60/3 1 n/a
200/60/3 2 3 12/6 1.5 6.5 7.3 1.2 320-320/386 2156-2156/2525 701-701/821 804/526 1000/800
230/60/3 1 n/a
230/60/3 2 3 12/6 1.5 6.5 7.3 1.2 278-278/336 1756-1756/2126 571-571/691 709/463 800/700
380/60/3 1 n/a
380/60/3 2 3 12/6 1.5 3.5 3.7 1.2 168-168/203 1060-1060/1306 345-345/424 423/277 500/450
460/60/3 1 3 18 1.5 3 3.7 1.2 139-139/168 878-878/1065 285-285/346 548 700
460/60/3 2 3 12/6 1.5 3 3.7 1.2 139-139/168 878-878/1065 285-285/346 352/231 450/350
575/60/3 1 3 18 1.5 2.5 3.7 1.2 111-111/134 705-705/853 229-229/277 441 500
575/60/3 2 3 12/6 1.5 2.5 3.7 1.2 111-111/134 705-705/853 229-229/277 284/185 350/300
400/50/3 1 3 18 1.5 2.8 3.7 1.2 168-168/198 1089-1089/1089 354-354/354 641 800
400/50/3 2 3 12/6 1.5 2.8 3.7 1.2 168-168/198 1089-1089/1089 354-354/354 416/267 500/450
300
200/60/3 1 n/a
200/60/3 2 3 14/6 1.5 6.5 7.3 1.2 386-386/386 2525-2525/2525 821-821/821 965/526 1200/800
230/60/3 1 n/a
230/60/3 2 3 14/6 1.5 6.5 7.3 1.2 336-336/336 2126-2126/2126 691-691/691 852/463 1000/700
380/60/3 1 n/a
380/60/3 2 3 14/6 1.5 3.5 3.7 1.2 203-203/203 1306-1306/1306 424-424/424 508/277 700/450
460/60/3 1 3 20 1.5 3 3.7 1.2 168-168/168 1065-1065/1065 346-346/346 612 700
460/60/3 2 3 14/6 1.5 3 3.7 1.2 168-168/168 1065-1065/1065 346-346/346 423/231 500/350
575/60/3 1 3 20 1.5 2.5 3.7 1.2 134-134/134 853-853/853 277-277/277 492 600
575/60/3 2 3 14/6 1.5 2.5 3.7 1.2 134-134/134 853-853/853 277-277/277 340/185 450/300
400/50/3 1 3 20 1.5 2.8 3.7 1.2 198-198/198 1089-1089/1089 354-354/354 706 900
400/50/3 2 3 14/6 1.5 2.8 3.7 1.2 198-198/198 1089-1089/1089 354-354/354 489/267 600/450
Table 37. High efficiency - high and wide ambient options (continued)
Unit
Size
Rated
Voltage
1
#
Power
Conn
2
#
Comp
# Fan
Ckt1/
Ckt2
Fan
kW
Fan
FLA
VFD
Input
Cntrl
VA
3
RLA
4
Ckt1/Ckt2
XLRA
5
Ckt1/Ckt2
YLRA
5
Ckt1/Ckt2
MCA
6
Ckt1/
Ckt2
MOP
7
Ckt1/
Ckt2
