Installation - Electrical
82 RTAC-SVX01J-EN
400
200A n/a
(4) 2 AWG -
600 MCM
(4) 250 MCM -
500 MCM
(4) 250 MCM -
500 MCM
(4) 2 AWG -
600 MCM
(4) 250 MCM -
500 MCM
(4) 250 MCM -
500 MCM
230A n/a
(4) 2 AWG -
600 MCM
(4) 250 MCM -
500 MCM
(4) 250 MCM -
500 MCM
(4) 2 AWG -
600 MCM
(4) 250 MCM -
500 MCM
(4) 250 MCM -
500 MCM
380A n/a
(3 ) 2 AWG -
600 MCM
(3) 1/0 AWG -
500 MCM
(3) 1/0 AWG -
500 MCM
(3) 2 AWG -
600 MCM
(3) 1/0 AWG -
500 MCM
(3) 1/0 AWG -
500 MCM
460A n/a
(4) 2 AWG -
600 MCM
(2) 2 AWG -
600 MCM
(2) 3/0 AWG -
500 MCM
(2) 3/0 AWG -
500 MCM
(2) 2 AWG -
600 MCM
(2) 3/0 AWG -
500 MCM
(2) 3/0 AWG -
500 MCM
575A n/a
(4) 2 AWG -
600 MCM
(2) 2 AWG -
600 MCM
(2) 3/0 AWG -
500 MCM
(2) 3/0 AWG -
500 MCM
(2) 2 AWG -
600 MCM
(2) 3/0 AWG -
500 MCM
(2) 3/0 AWG -
500 MCM
400B n/a
(4) 2 AWG -
600 MCM
(2) 2 AWG -
600 MCM
(2) 3/0 AWG -
500 MCM
(2) 3/0 AWG -
500 MCM
(2) 2 AWG -
600 MCM
(2) 3/0 AWG -
500 MCM
(2) 3/0 AWG -
500 MCM
450
200A n/a
(4) 2 AWG -
600 MCM
(4) 250 MCM -
500 MCM
(4) 250 MCM -
500 MCM
(4) 2 AWG -
600 MCM
(4) 250 MCM -
500 MCM
(4) 250 MCM -
500 MCM
230A n/a
(4) 2 AWG -
600 MCM
(4) 250 MCM -
500 MCM
(4) 250 MCM -
500 MCM
(4) 2 AWG -
600 MCM
(4) 250 MCM -
500 MCM
(4) 250 MCM -
500 MCM
380A n/a
(3 ) 2 AWG -
600 MCM
(3) 1/0 AWG -
500 MCM
(3) 1/0 AWG -
500 MCM
(3) 2 AWG -
600 MCM
(3) 1/0 AWG -
500 MCM
(3) 1/0 AWG -
500 MCM
460A n/a
(4) 2 AWG -
600 MCM
(2) 2 AWG -
600 MCM
(2) 3/0 AWG -
500 MCM
(2) 3/0 AWG -
500 MCM
(2) 2 AWG -
600 MCM
(2) 3/0 AWG -
500 MCM
(2) 3/0 AWG -
500 MCM
575A n/a
(4) 2 AWG -
600 MCM
(2) 2 AWG -
600 MCM
(2) 3/0 AWG -
500 MCM
(2) 3/0 AWG -
500 MCM
(2) 2 AWG -
600 MCM
(2) 3/0 AWG -
500 MCM
(2) 3/0 AWG -
500 MCM
500
200A n/a
(4) 2 AWG -
600 MCM
(4) 250 MCM -
500 MCM
(4) 250 MCM -
500 MCM
(4) 2 AWG -
600 MCM
(4) 250 MCM -
500 MCM
(4) 250 MCM -
500 MCM
230A n/a
(4) 2 AWG -
600 MCM
(4) 250 MCM -
500 MCM
(4) 250 MCM -
500 MCM
(4) 2 AWG -
600 MCM
(4) 250 MCM -
500 MCM
(4) 250 MCM -
500 MCM
380A n/a
(3 ) 2 AWG -
600 MCM
(3) 1/0 AWG -
500 MCM
(3) 1/0 AWG -
500 MCM
(3) 2 AWG -
600 MCM
(3) 1/0 AWG -
500 MCM
(3) 1/0 AWG -
500 MCM
460A n/a
(4) 2 AWG -
600 MCM
(2) 2 AWG -
600 MCM
(2) 3/0 AWG -
500 MCM
(2) 3/0 AWG -
500 MCM
(2) 2 AWG -
600 MCM
(2) 3/0 AWG -
500 MCM
(2) 3/0 AWG -
500 MCM
575A n/a
(4) 2 AWG -
600 MCM
(2) 2 AWG -
600 MCM
(2) 3/0 AWG -
500 MCM
(2) 3/0 AWG -
500 MCM
(2) 2 AWG -
600 MCM
(2) 3/0 AWG -
500 MCM
(2) 3/0 AWG -
500 MCM
1. Non-fused unit disconnect and circuit breaker are optional.
2. Copper wire only, based on nameplate minimum circuit ampacity (MCA).
3. Circuit breaker sizes are for factory mounted only.
4. n/a - not available
Table 39. Customer wire selection - standard and high efficiencies (continued)
Single point power Dual point power - Ckt 1 Dual point power - Ckt 2
Unit
Size Volt Term Disc
Circuit
Breaker Term Disc
Circuit
Breaker Term Disc
Circuit
Breaker
