SS-SVX11K-EN
115
Figure 76. 25 Ton cooling cycle pressure curve
105°F OD
95°F OD
85°F OD
75°F OD
65°F OD
Suction pressure, PSIG
95 105 115 125 135 145
250
300
350
400
450
500
550
Discharge pressure, PSIG
25T Cooling Cycle Pressure Curve
All compressors and condenser fans running
Figure 77. 30 Ton cooling cycle pressure curve
105°F OD
95°F OD
85°F OD
75°F OD
65°F OD
Suction pressure, PSIG
95 105 115 125 135 145
250
300
350
400
450
500
550
Discharge pressure, PSIG
30T Cooling Cycle Pressure Curve
All compressors and condenser fans running
Figure 78. 40 Ton cooling cycle pressure curve
105°F OD
95°F OD
85°F OD
75°F OD
65°F OD
Suction pressure, PSIG
95 105 115 125 135 145
250
300
350
400
450
500
550
Discharge pressure, PSIG
40T Cooling Cycle Pressure Curve
All compressors and condenser fans running
Figure 79. 50 Ton cooling cycle pressure curve
105°F OD
95°F OD
85°F OD
75°F OD
65°F OD
Suction pressure, PSIG
95 105 115 125 135 145
250
300
350
400
450
500
550
Discharge pressure, PSIG
50T Cooling Cycle Pressure Curve
All compressors and condenser fans running
Figure 80. 60 Ton cooling cycle pressure curve
105°F OD
95°F OD
85°F OD
75°F OD
65°F OD
Suction pressure, PSIG
95 105 115 125 135 145
250
300
350
400
450
500
550
Discharge pressure, PSIG
60T Cooling Cycle Pressure Curve
All compressors and condenser fans running
Figure 81. 80 Ton cooling cycle pressure curve
105°F OD
95°F OD
85°F OD
75°F OD
65°F OD
Suction pressure, PSIG
95 105 115 125 135 145
250
300
350
400
450
500
550
Discharge pressure, PSIG
80T Cooling Cycle Pressure Curve
All compressors and condenser fans running
SSttaarrtt--UUpp
