General Information
Unit Inspection
To protect against loss due to damage incurred in
transit, perform inspection immediately upon receipt of
the unit.
Exterior Inspection
If the job site inspection reveals damage or material
shortages, file a claim with the carrier immediately.
Specify the type and extent of the damage on the bill of
lading before signing. Notify the appropriate sales
representative.
IImmppoorrttaanntt:: Do not proceed with installation of a
damaged unit without sales
representative’s approval.
• Visually inspect the complete exterior for signs of
shipping damages to unit or packing material.
• Verify that the nameplate data matches the sales
order and bill of lading.
• Verify that the unit is properly equipped and there
are no material shortages.
• Verify that the power supply complies with the unit
nameplate and electric heater specifications.
Inspection for Concealed Damage
Visually inspect the components for concealed damage
as soon as possible after delivery and before it is
stored.
Do NOT walk on the sheet metal base pans. Bridging
between the unit’s main supports may consist of
multiple 2 by 12 boards or sheet metal grating.
WWAARRNNIINNGG
NNoo SStteepp SSuurrffaaccee!!
FFaaiilluurree ttoo ffoollllooww iinnssttrruuccttiioonn bbeellooww ccoouulldd rreessuulltt iinn
ddeeaatthh oorr sseerriioouuss iinnjjuurryy..
DDoo nnoott wwaallkk oonn tthhee sshheeeett mmeettaall ddrraaiinn ppaann.. WWaallkkiinngg
oonn tthhee ddrraaiinn ppaann ccoouulldd ccaauussee tthhee ssuuppppoorrttiinngg mmeettaall
ttoo ccoollllaappssee aanndd rreessuulltt iinn tthhee ooppeerraattoorr//tteecchhnniicciiaann
ffaalllliinngg..
If concealed damage is discovered:
• Notify the carrier’s terminal of the damage
immediately by phone and by mail.
• Concealed damage must be reported within 15
days.
• Request an immediate, joint inspection of the
damage with the carrier and consignee.
• Stop unpacking the unit.
• Do not remove damaged material from receiving
location.
• Take photos of the damage, if possible.
• The owner must provide reasonable evidence that
the damage did not occur after delivery.
Repair
Notify the appropriate sales representative before
arranging unit installation or repair.
IImmppoorrttaanntt:: Do not repair unit until the damage has
been inspected by the carrier’s
representative.
Nameplates
Unit Nameplate
One Mylar unit nameplate is located on the outside
upper right corner of the control panel door. It includes
the unit model number, serial number, electrical
characteristics, weight, refrigerant charge, as well as
other pertinent unit data. A small metal nameplate with
model number, serial number, and unit weight is
located just above the Mylar nameplate, and a third
nameplate is located on the inside of the control panel
door.
When ordering replacement parts or requesting
service, be sure to refer to the specific model number,
serial number, and DL number (if applicable) stamped
on the unit nameplate.
Compressor Nameplate
The nameplate for the scroll compressors is located on
the lower housing of the compressor.
EVP Chiller — Applications Only
If ordered with remote EVP chiller kit, piping
components ship in condenser section. The heat
exchanger ships separately. Location of nameplate
depends on size.
• 20-30 ton chiller: same side as water connections
near center left.
• 40-120 ton chiller: same side as water connections
near bottom.
To view nameplate, raise insulation flap over
nameplate. Replace and retape insulation flap after
viewing.
Unit Protection
Phase Monitor (1U3)
The unit is equipped with a phase monitor in the
control box. The phase monitor will protect against
phase loss, imbalance and reversal of the line voltage.
If a fault occurs, the red LED will energize. While the
fault condition is present the phase monitor interrupts
