58
SS-SVX11K-EN
Braze Plate (BPHE) Chiller
Evaporator water inlet and outlet types, sizes and
locations are shown in drawings in Dimensions and
Weights chapter. Installation of a field provided 1/2” x
14 NPTE stainless steel or PVC plug is required.
Strainer
Install a strainer in the water supply line to protect the
chiller from plugging with system piping debris.
Strainers should be installed as close as practical to the
heat exchanger water inlet (the remote chiller
accessory kit includes strainer and piping to connect
with BPHE). A field provided blow down valve
(recommended) or plug must be installed in strainer
cleanout if not present.
Table 17. Chiller water pressure drop, Ft H2O
Flow
(GPM)
Size, Tons
20 25 30 40 50 60 80 100 120
25 3.7
30 5.2 3.2
35 6.9 4.2
40 8.8 5.4 3.1
45 10.9 6.7 3.9
50 13.3 8.2 4.8 5.3
60 18.5 11.4 6.7 7.5 4.1
70 24.6 15.2 8.9 10.1 5.5
80 19.4 11.4 13.0 7.1 5.0
90 24.1 14.2 16.3 8.9 6.3
100 17.3 19.9 10.9 7.7 4.3
120 28.3 15.4 10.9 6.1 3.2
140 20.7 14.6 8.2 4.4
160 26.7 18.9 10.6 5.6 4.8
180 23.6 13.2 7.1 6.1
200 16.2 8.7 7.4
240 22.9 12.3 10.6
280 16.5 14.2
320 21.3 18.3
360 26.7 23.0
400 28.2
Chilled Water Flow Switch
NNOOTTIICCEE
EEvvaappoorraattoorr DDaammaaggee!!
FFaaiilluurree ttoo ffoollllooww iinnssttrruuccttiioonnss ccoouulldd rreessuulltt
eevvaappoorraattoorr ddaammaaggee..
TToo pprreevveenntt eevvaappoorraattoorr ddaammaaggee,, ddoo nnoott uussee wwaatteerr
ffllooww sswwiittcchh ttoo ccyyccllee tthhee ssyysstteemm..
NNOOTTIICCEE
HHeeaatt EExxcchhaannggeerr aanndd CCoommpprreessssoorr
DDaammaaggee!!
WWaatteerr ffllooww rraatteess bbeeyyoonndd tthhee hheeaatt eexxcchhaannggeerr lliimmiittss
ccoouulldd rreessuulltt iinn ppeerrmmaanneenntt ddaammaaggee ttoo tthhee hheeaatt
eexxcchhaannggeerr aanndd//oorr ccoommpprreessssoorr..
DDoo nnoott ooppeerraattee oouuttssiiddee rreeccoommmmeennddeedd ffllooww rraatteess..
IInnssttaallllaattiioonn MMeecchhaanniiccaall —— EEVVPP
