General Data
RTAF High Seasonal Effi ciency - eXtra Low Noise RTAF RTAF RTAF RTAF RTAF RTAF RTAF RTAF
090 105 125 145 155 175 190 205
Eurovent Performances HSE XLN HSE XLN HSE XLN HSE XLN HSE XLN HSE XLN HSE XLN HSE XLN
Net Cooling Capacity (3) (4) (kW) 330 383 451 533 575 638 694 755
Power Input (5) (kW) 100 119 144 165 184 206 221 243
EER (3) (4) (6) (kW/kW) 3.29 3.21 3.13 3.22 3.12 3.10 3.14 3.11
ESEER (6) (kW/kW) 4.46 4.43 4.62 4.77 4.68 4.62 4.62 4.61
Eurovent Effi ciency class Cooling AA AA A AA A
Sound power level (eXtra Low Noise) (10) (dBA) 88 88 88 89 90 90 91 91
Middle East design condition performances (7)
Gross cooling capacity (tons) 78 91 107 127 135 151 166 180
Gross EER (kW/ton) 1.46 1.48 1.53 1.47 1.54 1.54 1.49 1.52
MEW (Kuwait) rating point performances (8)
Gross cooling capacity (tons) 75 88 103 122 130 145 161 174
Gross EER (kW/ton) 1.56 1.58 1.63 1.58 1.64 1.64 1.58 1.61
Table 7 – General Data RTAF 090 – 205 High Seasonal Effi ciency - Extra Low Noise
Compressor
Quantity # 22222222
Nominal Size (1) tons 45/45 50/50 70/50 70/70 85/70 100/70 100/85 100/100
Evaporator
Evaporator Model 115B 115A 165B 165B 165A 200B 200B 250B
Water Storage l 51 58 74 74 78 99 99 118
Two pass Evaporator
Minimum Flow l/s 8.0 9.4 11.6 11.6 12.4 14.2 14.2 17.9
Maximum Flow l/s 29.6 34.7 43.1 43.1 46.0 52.6 52.6 66.5
Two pass Evaporator – With Turbulators
Minimum Flow l/s 6.6 7.8 9.7 9.7 10.3 11.8 11.8 14.9
Maximum Flow l/s 26.6 31.2 38.7 38.7 41.3 47.2 47.2 59.7
Condenser
Quantity of Coils # 5/5 5/5 5/5 6/6 6/6 7/5 7/7 7/7
Coil Length mm 1967 1967 1967 1967 1967 1967 1967 1967
Coil Height mm 1214 1214 1214 1214 1214 1214 1214 1214
Condenser Fans
Quantity (1) # 5/5 5/5 5/5 6/6 6/6 7/5 7/7 7/7
Diameter mm 800 800 800 800 800 800 800 800
Total Air Flow m
3
/s 4.2 4.8 4.8 4.8 4.8 5.6 5.6 5.6
Nominal RPM rpm 660 760 760 760 760 860 860 860
Motor kW 0.5 0.8 0.8 0.8 0.8 1.1 1.1 1.1
Minimum Starting/Operating Ambient
Standard Unit °C -10 -10 -10 -10 -10 -10 -10 -10
Low-Ambient Unit (Option) °C -20 -20 -20 -20 -20 -20 -20 -20
Maximum ambient operation
Standard ambient (9)
°C 46 46 46 46 46 46 46 46
Maximum ambient operation
High ambient (9)
°C 55 55 55 55 55 55 55 55
General Unit
Refrigerant HFC134a HFC134a HFC134a HFC134a HFC134a HFC134a HFC134a HFC134a
Number of Independent
Refrigerant Circuits # 22222222
Minimum Load (2) % 15 15 15 15 15 15 15 15
Operating Weight kg 3805 3865 4045 4570 4880 5035 5545 5660
Shipping Weight kg 3746 3797 3959 4484 4790 4920 5430 5533
R134a refrigerant charge
Circuit1/Circuit 2
(kg) 42/41 40/39 44/43 46/45 50/44 61/52 62/59 67/65
Oil charge Circuit1/Circuit 2 (l) 6/6 6/6 6/6 6/6 7/6 7/6 7/7 8/8
Notes:
1. Data containing information on two circuits shown as follows: ckt1/ckt2.
2. Percent minimum load is for total machine at 10°C ambient and 7°C leaving chilled water temperature, not each
individual circuit.
3. Net cooling capacity at Eurovent conditions, 7°C leaving water temperature and 35°C entering condenser air
temperature.
4. Ratings based on sea level altitude and evaporator fouling factor 0.017645 m²K/kW.
5. Unit kW input, including fans.
6. Calculate with cooling capacity.
7. At Evaporator water temperature: 6.6°C (44°F)/12.2°C (54°F) - Condenser air temperature 46°C (114.8°F).
8. At Evapotator water temperature: 6.6°C (44°F)/12.2°C (54°F) - Condenser air temperature 48°C (118.4°F),
according to Code of practice MEW/R-6/2010 issued by Kuwaiti Ministry of Electricity and Water (MEW).
9. Maximum ambient operation is for unit at 12°C/7°C.
10. At Eurovent conditions, with 1pW Reference Sound Power, according to ISO9614.
