S9V2-SVX001-1A-EN
25
Table 14. S9V2B080U4PSBC/D / S9V2B080D4PSBC/D Cooling Airflow (continued)
S9V2B080U4PSBC/D / S9V2B080D4PSBC/D Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static
Pressure with Filter
Cooling
Unit
Outdoor
Airflow
Setting
(CFM/ton)
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Cooling
4.0 Ton
(a)
Cooling 450
CFM/Ton
CFM 1769 1791 1797 1789 1766
Watts 570 648 725 799 873
Cooling 420
CFM/Ton
CFM 1650 1670 1675 1664 1639
Watts 469 544 616 686 756
Cooling 400
CFM/Ton
CFM 1571 1590 1593 1582 1555
Watts 410 481 550 618 685
Cooling 370
CFM/Ton
CFM 1453 1470 1472 1458 1430
Watts 330 397 462 526 588
Cooling 350
CFM/Ton
(a)
CFM 1375 1391 1391 1376 1347
Watts 284 348 410 471 530
Cooling 330
CFM/Ton
CFM 1297 1312 1311 1295 1265
Watts 242 303 363 420 477
Cooling 310
CFM/Ton
CFM 1219 1233 1230 1214 1183
Watts 205 263 319 374 428
Cooling 290
CFM/Ton
CFM 1142 1154 1151 1133 1101
Watts 172 227 280 332 384
(a)
Factory Setting.
Table 15. S9V2C080U5PSBC Heating Airflow
S9V2C080U5PSBC Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 50,600
2nd Stage Capacity = 77,750
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 857
CFM 837 870 902 934 967
Temp. Rise
55 53 51 50 48
Watts 65 112 160 208 256
Medium Low
(a)
1044
CFM 997 1015 1033 1050 1068
Temp. Rise
46 45 45 44 43
Watts 102 155 209 263 316
Medium 1123
CFM 1067 1094 1121 1148 1175
Temp. Rise
43 42 41 40 39
Watts 123 180 236 293 350
High
1498
CFM 1420 1416 1411 1407 1402
Temp. Rise
32 33 33 33 34
Watts 238 320 402 485 567
Heating 2nd
Stage
Low 1190
CFM 1129 1148 1168 1188 1208
Temp. Rise
63 62 61 60 59
Watts 127 195 263 331 399
Medium Low
(a)
1450
CFM 1387 1395 1404 1412 1420
Temp. Rise
52 51 51 51 51
Watts 248 310 372 434 496
Medium 1560
CFM 1484 1498 1512 1525 1539
Temp. Rise
48 48 47 47 47
Watts 281 358 435 512 589
High
2080
CFM 1954 1956 1959 1961 1964
Temp. Rise
37 37 37 37 37
Watts 597 732 866 1001 1135
(a)
Factory Setting.
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
