Table 22. S9V2D120D5PSBC/D Heating Airflow
S9V2D120D5PSBC/D Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure
with Filter (iwc)
1st Stage Capacity = 75,800
2nd Stage Capacity = 116,100
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 1160
CFM 1234 1240 1246 1252 1258
Temp. Rise
56 56 56 55 55
Watts 137 198 258 319 380
Medium Low 1332
CFM 1305 1311 1318 1325 1332
Temp. Rise
53 53 53 52 52
Watts 158 221 284 347 410
Medium 1404
CFM 1324 1510 1697 1884 2070
Temp. Rise
53 46 39 32 25
Watts 179 246 313 380 447
High
(a)
1620
CFM 1598 1484 1371 1257 1144
Temp. Rise
44 47 49 52 54
Watts 266 316 366 416 466
Heating 2nd
Stage
Low 1750
CFM 1687 1673 1659 1645 1631
Temp. Rise
63 64 64 65 65
Watts 327 407 487 568 648
Medium Low 1850
CFM 1788 1771 1754 1738 1721
Temp. Rise
60 60 61 61 62
Watts 380 464 549 633 718
Medium 1950
CFM 1891 1862 1833 1803 1774
Temp. Rise
56 57 58 60 61
Watts 424 524 624 724 824
High
(a)
2250
CFM 2080 2100 2120 2140 2160
Temp. Rise
51 51 51 51 51
Watts 708 768 828 888 948
(a)
Factory Setting.
