Trane S9V2B040U3PSBC/D User Manual

S9V2-SVX001-1A-EN
33
Table 23. S9V2D120U5PSBC/D / S9V2D120D5PSBC/D Cooling Airflow (continued)
S9V2D120U5PSBC/D / S9V2D120D5PSBC/D Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static
Pressure with Filter (iwc)
Cooling
Unit
Outdoor
Airflow
Setting
(CFM/ton)
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Cooling
5.0 Ton
(a)
Cooling 450
CFM/Ton
CFM 2238 2235 2230 2226 2220
Watts 646 742 840 938 1036
Cooling 420
CFM/Ton
CFM 2086 2086 2085 2083 2080
Watts 533 623 714 806 897
Cooling 400
CFM/Ton
CFM 1985 1987 1988 1988 1986
Watts 466 552 639 726 813
Cooling 370
CFM/Ton
CFM 1834 1838 1842 1844 1845
Watts 377 456 536 617 698
Cooling 350
CFM/Ton
(a)
CFM 1733 1740 1745 1748 1750
Watts 324 399 475 552 628
Cooling 330
CFM/Ton
CFM 1633 1641 1647 1652 1655
Watts 277 347 419 492 564
Cooling 310
CFM/Ton
CFM 1534 1543 1550 1555 1558
Watts 234 301 369 437 505
Cooling 290
CFM/Ton
CFM 1435 1444 1452 1458 1461
Watts 196 259 322 387 451
(a)
Factory Setting.
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
