S9V2-VS-SVX001-1C-EN
93
Motor
Communications
Personality
Module
Low Voltage Terminal Strip
12 Pin
Connector
LINE
Connections
EAC Dry Contact
HUM Dry Contact
Neutral
Connections
VSPD Inducer
Connector
Igniter
Connector
7 Segment LED
MENU and OPTION
Select Buttons
5 Amp Fuse
BK Jumper
FP - Flame Sensor
Connector
IFC Component Layout
TTrroouubblleesshhoooottiinngg
