Table 15. S9V2D120U5VSAC/D Cooling Airflow (continued)
S9V2D120U5VSAC/D Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Outdoor
Tonnage -
"Odt" (tons)
Airflow
Setting -
(CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
4.0
450
CFM / WATTS 1783 / 350 1789 / 427 1793 / 505 1796 / 584 1798 / 663
420
CFM / WATTS 1663 / 290 1671 / 362 1677 / 436 1681 / 509 1683 / 583
400
CFM / WATTS 1584 / 255 1592 / 324 1599 / 393 1603 / 464 1607 / 534
370
CFM / WATTS 1465 / 207 1474 / 271 1481 / 336 1487 / 401 1491 / 467
350
CFM / WATTS 1386 / 179 1395 / 240 1403 / 301 1409 / 363 1413 / 426
330
CFM / WATTS 1307 / 154 1317 / 211 1324 / 269 1330 / 328 1334 / 388
310
CFM / WATTS 1228 / 131 1238 / 185 1246 / 240 1251 / 296 1254 / 352
290
CFM / WATTS 1150 / 111 1159 / 162 1166 / 214 1171 / 266 1174 / 320
5.0
(a)
450
CFM / WATTS 2238 / 646 2235 / 742 2230 / 840 2226 / 938 2220 / 1036
420
CFM / WATTS 2086 / 533 2086 / 623 2085 / 714 2083 / 806 2080 / 897
400
CFM / WATTS 1985 / 466 1987 / 552 1988 / 639 1988 / 726 1986 / 813
370
CFM / WATTS 1834 / 377 1838 / 456 1842 / 536 1844 / 617 1845 / 698
350
(a)
CFM / WATTS 1733 / 324 1740 / 399 1745 / 475 1748 / 552 1750 / 628
330
CFM / WATTS 1633 / 277 1641 / 347 1647 / 419 1652 / 492 1655 / 564
310
CFM / WATTS 1534 / 234 1543 / 301 1550 / 369 1555 / 437 1558 / 505
290
CFM / WATTS 1435 / 196 1444 / 259 1452 / 322 1458 / 387 1461 / 451
(a)
Factory Setting.
