Table 17. Supply Duct Connections (continued)
Furnace in Horizontal Right with “A” Coil Furnace in Horizontal Right with “A” Coil
Refer to Step 10., Step 4.
Note: Flat or dedicated horizontal coils may require flanges to be bent
upward.
Refer to Step 7., Step 8., Step 9., Step 6.
Downflow Furnace with Coil Downflow Furnace with Coil
Refer to Step 11., Step 4.
Note: 4GXC* or 4MXC* coils installed on a downflow furnace do not
require a metal drain pan shield or the use of the
MAY*FERCOLKITAA kit.
Refer to Step 7., Step 8., Step 9., Step 6.
