Trane S9V2B080D4PSBC/D - Page 20

20
S9V2-SVX001-1A-EN
Table 9. S9V2B060D3PSBC/D Cooling Airflow
S9V2B060D3PSBC/D Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Cooling
Unit
Outdoor
Airflow
Setting
(CFM/ton)
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Cooling
1.5 Ton
Cooling 450
CFM/Ton
CFM 672 674 672 666 656
Watts 48 84 122 161 203
Cooling 420
CFM/Ton
CFM 626 628 627 622 612
Watts 41 76 112 150 190
Cooling 400
CFM/Ton
CFM 595 598 597 592 583
Watts 37 70 105 143 182
Cooling 370
CFM/Ton
CFM 549 553 552 547 538
Watts 32 63 97 133 171
Cooling 350
CFM/Ton
CFM 518 522 522 518 509
Watts 29 59 91 126 164
Cooling 330
CFM/Ton
CFM 487 492 492 488 479
Watts 26 55 86 121 158
Cooling 310
CFM/Ton
CFM 456 461 462 458 449
Watts 23 51 81 115 153
Cooling 290
CFM/Ton
CFM 425 431 432 428 420
Watts 21 47 77 111 148
Cooling
2.0 Ton
Cooling 450
CFM/Ton
CFM 894 891 882 871 873
Watts 91 137 182 228 282
Cooling 420
CFM/Ton
CFM 838 839 835 827 816
Watts 78 122 166 212 259
Cooling 400
CFM/Ton
CFM 798 799 795 788 778
Watts 70 112 155 199 244
Cooling 370
CFM/Ton
CFM 737 739 736 730 719
Watts 58 98 138 180 223
Cooling 350
CFM/Ton
CFM 697 699 697 690 680
Watts 52 89 128 168 211
Cooling 330
CFM/Ton
CFM 656 659 657 651 641
Watts 46 81 118 157 199
Cooling 310
CFM/Ton
CFM 616 618 617 612 602
Watts 40 74 110 147 187
Cooling 290
CFM/Ton
CFM 575 578 577 572 563
Watts 35 67 101 138 177
Cooling
2.5 Ton
Cooling 450
CFM/Ton
CFM 1120 1117 1111 1102 1089
Watts 162 218 275 332 390
Cooling 420
CFM/Ton
CFM 1037 1035 1029 1020 1008
Watts 132 185 238 291 346
Cooling 400
CFM/Ton
CFM 997 996 991 982 970
Watts 120 171 222 274 327
Cooling 370
CFM/Ton
CFM 923 923 918 910 898
Watts 99 146 194 243 293
Cooling 350
CFM/Ton
CFM 873 873 869 861 850
Watts 86 132 177 224 273
Cooling 330
CFM/Ton
CFM 823 824 820 813 802
Watts 75 118 162 207 253
Cooling 310
CFM/Ton
CFM 773 774 771 764 754
Watts 65 106 147 191 235
Cooling 290
CFM/Ton
CFM 722 724 721 715 705
Watts 56 94 134 175 218
Cooling
3.0 Ton
(a)
Cooling 450
CFM/Ton
CFM 1336 1332 1324 1313 1299
Watts 263 329 395 462 529
Cooling 420
CFM/Ton
CFM 1250 1247 1239 1229 1216
Watts 218 280 343 406 470
Cooling 400
CFM/Ton
CFM 1193 1189 1183 1173 1159
Watts 191 251 311 372 433
Cooling 370
CFM/Ton
CFM 1105 1103 1097 1087 1075
Watts 156 212 268 325 382
Cooling 350
CFM/Ton
(a)
CFM 1046 1045 1039 1030 1018
Watts 135 189 242 296 351
Cooling 330
CFM/Ton
CFM 987 986 981 973 961
Watts 117 167 218 270 322
Cooling 310
CFM/Ton
CFM 928 927 923 915 903
Watts 100 148 196 245 295
Cooling 290
CFM/Ton
CFM 868 868 864 857 845
Watts 85 130 176 223 271
(a)
Factory Setting.
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
