12
S9V2-VS-SVX001-1B-EN
Model
S9V2B080D4VSAC/D
(a)
,
(b)
S9V2C100D4VSAC/D
(a)
,
(b)
Type
Downflow
RATINGS
(c)
1st Stage Input BTUH 52,000 65,000
1st Stage Capacity BTUH (ICS) 51,150 64,300
2nd Stage Input BTUH 80,000 100,000
2nd Stage Capacity BTUH (ICS)
(d)
76,900 97,071
1st Stage Temp. Rise (Min. - Max.) °F
30 - 60
2nd Stage Temp. Rise (Min. - Max.) °F
35 - 65
AFUE (%)
(d)
97.0
Return Air Temp. (Min. - Max.) °F
45°F - 80°F
BLOWER DRIVE DIRECT
Diameter - Width (in.)
11 X 8 11 X 10
No. Used 1
Speeds (No.)
Variable
CFM vs. in. w.g.
See Fan Performance Table
Motor HP
3/4
R.P.M. Variable
Volts / Ph / Hz 120 / 1 / 60
FLA
8 / 9.6
COMBUSTION FAN - Type Variable Speed
Drive - No. Speeds
Direct - Variable
Motor RPM
1/50 - 5000
Volts/Ph/Hz 33 - 110 / 3 / 60 - 180
FLA 0.77
Inducer Orifice 0.96 1.05
FILTER - Furnished? No
Type Recommended High Velocity
Hi Vel. (No.-Size-Thk.)
1 - 16 X 25 - 1 in. 1 - 20 X 25 - 1 in.
VENT OUTLET DIA - MIN. (in.)
(e)
2 Round
INLET AIR DIA - MIN. (in.)
(e)
2 Round
HEAT EXCHANGER – Type
Fired 409 Stainless Steel
Unfired 29-4C Stainless Steel
Gauge (Fired)
20
ORIFICES - Main
Nat. Gas (Qty. - Drill Size)
4 - 45 5 - 45
Propane Gas (Qty. - Drill Size)
4 - 56 5 - 56
GAS VALVE
Redundant - Two Stage
PILOT SAFETY DEVICE – TYPE
120 V SiNi Igniter
BURNERS - TYPE - QTY
Inshot - 4 Inshot - 5
POWER CONN. - V/Ph/HZ
(f)
120 / 1 / 60
Ampacity (Amps)
10.9 / 12.9
Max. Overcurrent Protection (Amps)
15
PIPE CONN. SIZE (IN.)
1/2
(a)
Meets Energy Star
(b)
Central Furnace heating designs are certified to ANSI Z21.47 / CSA 2.3 - latest edition.
(c)
For U.S. Applications, above input ratings (BTUH) are up to 2,000 feet, derate 4% per 1,000 feet for elevations above 2,000 feet above sea level. For
Canadian applications, above input ratings (BTUH) are up to 4,500 feet, derate 4% per 1,000 feet for elevations above 4,500 feet above sea level.
(d)
Based on U.S. government standard tests.
(e)
Refer to Vent Length Table in this document.
(f)
The above wiring specifications are in accordance with National Electrical Code; however, installations must comply with local codes.
PPrroodduucctt SSppeecciiffiiccaattiioonn
