Table 5. S9V2B040U3VSAE Cooling Airflow (continued)
S9V2B040U3VSAE Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Outdoor
Tonnage -
"Odt" (tons)
Airflow
Setting -
(CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
3.0
(a)
450
CFM / WATTS 1350 / 272 1350 / 334 1350 / 402 1298 / 440 1198 / 450
420
CFM / WATTS 1260 / 226 1260 / 284 1260 / 348 1260 / 417 1198 / 450
400
CFM / WATTS 1200 / 198 1200 / 254 1200 / 315 1200 / 381 1198 / 450
370
CFM / WATTS 1110 / 161 1110 / 213 1110 / 271 1110 / 333 1110 / 399
350
(a)
CFM / WATTS 1050 / 139 1050 / 188 1050 / 244 1050 / 304 1050 / 368
330
CFM / WATTS 990 / 119 990 / 166 990 / 219 990 / 277 990 / 338
310
CFM / WATTS 930 / 102 930 / 146 930 / 197 930 / 252 930 / 311
290
CFM / WATTS 870 / 86 870 / 128 870 / 176 870 / 229 870 / 285
Table 6. S9V2B060U3VSAC/D Heating Airflow
S9V2B060U3VSAC/D Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure
with Filter (iwc)
1st Stage Capacity = 38,450
2nd Stage Capacity = 57,700
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 632
CFM 660 658 656 654 652
Temp. Rise
53 53 53 53 54
Watts 48 85 121 157 193
Medium Low
(a)
814
CFM 860 856 852 848 844
Temp. Rise
41 41 42 42 43
Watts 91 128 164 200 236
Medium 893
CFM 900 899 898 897 896
Temp. Rise
39 39 39 39 39
Watts 110 147 183 219 255
High
1027
CFM 1068 1061 1054 1047 1041
Temp. Rise
33 33 33 33 33
Watts 165 202 239 276 313
Heating 2nd
Stage
Low 800
CFM 851 843 835 826 818
Temp. Rise
64 64 64 64 64
Watts 81 127 172 218 264
Medium Low
(a)
1030
CFM 1092 1075 1057 1039 1022
Temp. Rise
49 50 50 51 52
Watts 157 209 262 314 366
Medium 1130
CFM 1132 1128 1124 1119 1115
Temp. Rise
47 47 48 48 48
Watts 201 255 308 362 416
High
1300
CFM 1280 1281 1282 1283 1283
Temp. Rise
42 42 42 42 42
Watts 319 365 410 456 502
Table 7. S9V2B060U3VSAC/D Cooling Airflow
S9V2B060U3VSAC/D Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Outdoor
Tonnage -
"Odt" (tons)
Airflow
Setting -
(CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
1.5
450
CFM / WATTS 663 / 47 673 / 83 666 / 119 641 / 155 596 / 192
420
CFM / WATTS 621 / 41 630 / 75 621 / 109 595 / 144 549 / 180
400
CFM / WATTS 582 / 36 580 / 67 566 / 99 528 / 130 507 / 170
370
CFM / WATTS 549 / 32 556 / 63 546 / 95 517 / 128 469 / 162
350
CFM / WATTS 521 / 29 527 / 59 516 / 90 486 / 122 437 / 156
330
CFM / WATTS 492 / 26 497 / 55 486 / 85 455 / 117 405 / 150
310
CFM / WATTS 463 / 23 468 / 51 455 / 81 423 / 112 372 / 145
290
CFM / WATTS 435 / 21 438 / 48 424 / 77 391 / 107 339 / 141
2.0
450
CFM / WATTS 878 / 90 893 / 135 890 / 179 869 / 223 829 / 266
420
CFM / WATTS 821 / 76 834 / 119 830 / 161 808 / 202 767 / 244
400
CFM / WATTS 770 / 66 778 / 105 770 / 144 742 / 182 725 / 230
370
CFM / WATTS 725 / 57 737 / 96 731 / 134 707 / 172 664 / 211
350
CFM / WATTS 687 / 51 698 / 88 691 / 124 666 / 161 622 / 199
330
CFM / WATTS 649 / 45 659 / 80 651 / 115 625 / 151 580 / 188
310
CFM / WATTS 611 / 39 620 / 73 611 / 107 584 / 142 538 / 177
290
CFM / WATTS 573 / 34 581 / 67 571 / 99 543 / 133 496 / 168
