S9V2-VS-SVX001-1B-EN
Table 7. S9V2B060U3VSAC/D Cooling Airflow (continued)
S9V2B060U3VSAC/D Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Outdoor
Tonnage -
"Odt" (tons)
Airflow
Setting -
(CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
2.5
450
CFM / WATTS 1097 / 159 1114 / 212 1114 / 265 1097 / 317 1061 / 368
420
CFM / WATTS 1023 / 133 1040 / 184 1039 / 233 1020 / 282 984 / 331
400
CFM / WATTS 976 / 117 989 / 166 990 / 214 970 / 261 932 / 308
370
CFM / WATTS 902 / 97 917 / 142 915 / 187 894 / 232 855 / 276
350
CFM / WATTS 854 / 84 868 / 128 865 / 171 843 / 214 803 / 257
330
CFM / WATTS 806 / 73 819 / 115 815 / 157 793 / 198 752 / 239
310
CFM / WATTS 759 / 63 771 / 103 766 / 143 742 / 182 700 / 222
290
CFM / WATTS 711 / 55 722 / 93 716 / 130 692 / 168 648 / 206
3.0
(a)
450
CFM / WATTS 1319 / 260 1340 / 321 1343 / 382 1328 / 441 1295 / 501
420
CFM / WATTS 1229 / 215 1249 / 274 1251 / 331 1235 / 387 1201 / 443
400
CFM / WATTS 1170 / 189 1189 / 245 1190 / 300 1173 / 354 1139 / 408
370
CFM / WATTS 1082 / 154 1100 / 206 1099 / 258 1081 / 309 1046 / 360
350
(a)
CFM / WATTS 1023 / 133 1040 / 184 1039 / 233 1020 / 282 984 / 331
330
CFM / WATTS 965 / 114 981 / 163 979 / 210 960 / 257 922 / 304
310
CFM / WATTS 907 / 98 922 / 144 919 / 189 899 / 234 860 / 278
290
CFM / WATTS 850 / 83 863 / 127 860 / 170 838 / 212 798 / 255
Table 8. S9V2B080U4VSAC/D Heating Airflow
S9V2B080U4VSAC/D Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure
with Filter (iwc)
1st Stage Capacity = 51,050
2nd Stage Capacity = 76,700
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 864
CFM 860 849 838 827 816
Temp. Rise
54 55 56 57 58
Watts 87 125 163 200 238
Medium Low
(a)
907
CFM 907 893 879 865 852
Temp. Rise
51 52 53 54 54
Watts 97 135 174 212 251
Medium 958
CFM 957 930 903 876 849
Temp. Rise
49 50 51 52 53
Watts 112 153 194 234 275
High
1051
CFM 1042 1015 989 962 936
Temp. Rise
45 46 47 47 48
Watts 140 182 225 267 310
Heating 2nd
Stage
Low 1200
CFM 1211 1206 1201 1197 1192
Temp. Rise
60 60 60 60 60
Watts 196 248 300 352 404
Medium Low
(a)
1260
CFM 1258 1261 1263 1265 1268
Temp. Rise
58 57 57 57 57
Watts 215 271 326 381 436
Medium 1330
CFM 1307 1303 1299 1296 1292
Temp. Rise
55 55 55 55 55
Watts 260 312 364 416 468
High
1460
CFM 1431 1412 1393 1374 1355
Temp. Rise
50 51 52 52 53
Watts 334 390 445 501 557
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
