Trane Symbio 700 Controller User Manual

ACC-APG002A-EN
55
Table 24. Supported diagnostics and alarm relay functionality (continued)
Diagnostic/Alarm
Alarm Indicator
Diagnostic: Circuit 2 LPC Trip
N
Diagnostic: Comp 1 Proving Trip
N
Diagnostic: Comp 2 Proving Trip
N
Diagnostic: Maintenance Required
N
Discharge Air Temperature Local
Y
Outdoor Air Temperature Active
Y
Outdoor Air Humidity Active
Y
Space CO2 Concentration Active
N
Space Humidity Active
N
Space Temperature Active
Y
Diagnostic: Condensate Overflow Lockout
Y
Diagnostic: Supply Fan Proving Failure
Y
Diagnostic: ERM Supply Fan 1 Failure
Y
Diagnostic: ERM Supply Fan 2 Failure
Y
Diagnostic: ERM Supply Fan Locked Motor - 1
Y
Diagnostic: ERM Supply Fan Locked Motor - 2
Y
Diagnostic: ERM Supply Fan Motor Overheated - 1
Y
Diagnostic: ERM Supply Fan Motor Overheated - 2
Y
Diagnostic: ERM Supply Fan Power Mod Overheated - 1
Y
Diagnostic: ERM Supply Fan Power Mod Overheated - 2
Y
Supply Fan 1 Communication Status
Y
Supply Fan 2 Communication Status
Y
Diagnostic: ERM Fault Supply Fan - 1
Y
Diagnostic: ERM Fault Supply Fan - 2
Y
Phase Monitor Status Y
Diagnostic: Duct Static Pressure Local Trip
N
Diagnostic: Duct Static Pressure Local Lockout
Y
Diagnostic: Duct Static Pressure Limit Trip
N
Diagnostic: Duct Static Pressure Limit Lockout
Y
