Trane TCAA Series - General Data

10
ARTC-SVX013A-EN
General data
Table 2. General data - Packaged TCAA chiller
Model TCAA110AT TCAA150BT TCAA220BT TCAA330CT TCAA400DT TCAA440DT
Tonnage Range
80-120 110-165 165-240 250-360 350-420 400-450
General Unit
Number of Independent
Refrigeration Circuits
1 2 2 3 4 4
R-513A Refrigerant Charge (lbs/
Chiller) w/ECO
380 600 760 1080 1480 1520
Chilled Fluid Volume (gal/Chiller)
28.5 40 56.7 132 133.1 135.4
Compressor
Type
CENTRIFUGAL CENTRIFUGAL CENTRIFUGAL CENTRIFUGAL CENTRIFUGAL CENTRIFUGAL
Quantity
1 2 2 3 4 4
Evaporator
Type
SHELL AND TUBE SHELL AND TUBE SHELL AND TUBE SHELL AND TUBE SHELL AND TUBE SHELL AND TUBE
Quantity
1 1 1 1 1 1
Material (tubes/shell)
COPPER/STEEL COPPER/STEEL COPPER/STEEL COPPER/STEEL COPPER/STEEL COPPER/STEEL
Condenser
Coil Quantity
6 8 12 18 20 24
Coil Length (in)
80 80 80 80 80 80
Coil Height (in)
50 50 50 50 50 50
Fins/in. 14 14 14 14 14 14
Rows 5 5 5 5 5 5
Fan Quantity
6 8 12 18 20 24
Dimensions / Weights
Width (in)*
88 88 88 88 88 88
Depth (in)
175 225 325 478 540 680
Height (in)
98 to 106
Depending on fan
type
98 to 106
Depending on fan
type
98 to 106
Depending on fan
type
102 to 110
Depending on fan
type
97 to 106
Depending on fan
type
97 to 106
Depending on fan
type
Weight (lbs)* Shipping
10300 13500 18100 30000 32000 36000
Weight (lbs)* Operating
10600 13800 18500 32000 34000 38000
