Customer Responsibilities
Customer must inspect the unit upon receipt. Any visible
damage to shrink wrap would warrant the removal of the
shrink wrap for further inspection. Shrink wrap must be
reinstalled after inspection.
Visible damage must be noted on the signed and dated bill
of lading. The customer may request a carrier inspection by
telephone or in person, but any such request should be
confirmed in writing. It is recommended that the customer
request that the carrier inspect the damage within 72 hours
of notification.
If shrink wrap is damaged while in storage, shrink wrap
must be replaced/repaired before further transportation.
Failure to adhere to the long-term storage requirements
may void the Trane warranty. Any component that is
damaged or inoperable due to improper storage may have
its warranty voided.
Handling of the Chillers
The packaging from the factory permits lifting with a
suitable crane. Ensure straps are in good working condition
and that they are rated for the weight of the machines.
Spreader bars may be required for effective rigging and to
avoid damage to the chiller.
The chiller arrives fully charged with refrigerant. As
required under Federal regulations, installation, start-up
and service should be performed by fully qualified, factory-
certified, personnel.
WARNING
Proper Field Wiring and Grounding
Required!
Failure to follow code could result in death or serious
injury.
All field wiring MUST be performed by qualified
personnel. Improperly installed and grounded field
wiring poses FIRE and ELECTROCUTION hazards. To
avoid these hazards, you MUST follow requirements
for field wiring installation and grounding as
described in NEC and your local/state/national
electrical codes.
WARNING
Electrical Shock, Explosion, or Arc
Flash Hazard!
Failure to follow these instructions could result in
death or serious injury.
• Install the product in an appropriate electrical/
fire enclosure per local regulations. Do not
install the product in hazardous or classified
locations.
• Do not use the product for life or safety
applications.
• Do not exceed the product ratings or maximum
limits. Products rated only for basic insulation
must be installed on insulated conductors.
• Current transformer secondaries (current mode)
must be shorted or connected to a burden at all
times.
• Remove all wire scraps, tools, replace all doors,
covers and protective devices before powering
the equipment.
Site Preparation and Clearances
Chillers must be installed on a level surface that has been
checked by a qualified structural engineer to support the
weight of the fluid-filled units and the connective piping to
and from the chiller. Installations must account for minimum
service access clearances as may be practical or required
by local building codes.
Chiller Clearances
The National Electric Code or local, state, and regional
building codes may require greater clearance for the chiller
than the figures listed in this publication. Always consult
local regulatory agencies to ensure additional clearances
are not required by building codes.
Minimum Clearances
The unit must maintain a minimum of 72 inches clearance
on sides A, C, and D and a clearance of 72 inches plus
barrel length on side B, with no obstructions above chiller.
See Figure 2, p. 13.
Service Access
Compressors, filter-driers, and manual liquid line shutoff
valves are accessible on each side or end of the unit.
