Table 14. BMS analog data listing (continued)
Tag Name Description
Object
Type
Object Id
Modbus
Register
EIP Read Tag
Name
EIP Write Tag
Name
DTC2 Compressor Power
Compressor Power (Integer Value with 1 implied
decimal) - Compressor #2
AO 13 30013
AO_01_SC[12] WR_AO_01_SC[12]
DTC3 Compressor Power
Compressor Power (Integer Value with 1 implied
decimal) - Compressor #3
AO 14 30014
AO_01_SC[13] WR_AO_01_SC[13]
DTC4 Compressor Power
Compressor Power (Integer Value with 1 implied
decimal) - Compressor #4
AO 15 30015
AO_01_SC[14] WR_AO_01_SC[14]
DTC5 Compressor Power
Compressor Power (Integer Value with 1 implied
decimal) - Compressor #5
AO 16 30016
AO_01_SC[15] WR_AO_01_SC[15]
DTC6 Compressor Power
Compressor Power (Integer Value with 1 implied
decimal) - Compressor #6
AO 17 30017
AO_01_SC[16] WR_AO_01_SC[16]
Chiller External Load Limiting
Chiller External Load Limiting (Integer Value with 1
implied decimal)
AO 18 30018
AO_01_SC[17] WR_AO_01_SC[17]
Chiller Flow Setpoint
Chiller Flow Control Setpoint (Integer Value with
implied decimal)
AO 19 30019
AO_01_SC[18] WR_AO_01_SC[18]
DTC1 Suction Pressure
Suction Pressure (Integer Value with 1 implied
decimal) - Compressor #1
AO 20 30020
AO_01_SC[19] WR_AO_01_SC[19]
DTC2 Suction Pressure
Suction Pressure (Integer Value with 1 implied
decimal) - Compressor #2
AO 21 30021
AO_01_SC[20] WR_AO_01_SC[20]
DTC3 Suction Pressure
Suction Pressure (Integer Value with 1 implied
decimal) - Compressor #3
AO 22 30022
AO_01_SC[21] WR_AO_01_SC[21]
DTC4 Suction Pressure
Suction Pressure (Integer Value with 1 implied
decimal) - Compressor #4
AO 23 30023
AO_01_SC[22] WR_AO_01_SC[22]
DTC5 Suction Pressure
Suction Pressure (Integer Value with 1 implied
decimal) - Compressor #5
AO 24 30024
AO_01_SC[23] WR_AO_01_SC[23]
DTC6 Suction Pressure
Suction Pressure (Integer Value with 1 implied
decimal) - Compressor #6
AO 25 30025
AO_01_SC[24] WR_AO_01_SC[24]
ChillerStatus1
Separated into bits - Alarms and Faults
AO 26 30026
AO_01[25] WR_AO_01[25]
ChillerStatus2
Separated into bits - Alarms and Faults
AO 27 30027
AO_01[26] WR_AO_01[26]
Spare Unscaled Data 1
AO 28 30034
AO_01[33] WR_AO_01[33]
Spare Unscaled Data 2
AO 29 30035
AO_01[34] WR_AO_01[34]
DTC1 Compressor State
Compressor State (see Details Page for State
Enumeration) - Compressor #1
AO 30 30036
AO_01[35] WR_AO_01[35]
DTC2 Compressor State
Compressor State (see Details Page for State
Enumeration) - Compressor #2
AO 31 30037
AO_01[36] WR_AO_01[36]
DTC3 Compressor State
Compressor State (see Details Page for State
Enumeration) - Compressor #3
AO 32 30038
AO_01[37] WR_AO_01[37]
DTC4 Compressor State
Compressor State (see Details Page for State
Enumeration) - Compressor #4
AO 33 30039
AO_01[38] WR_AO_01[38]
DTC5 Compressor State
Compressor State (see Details Page for State
Enumeration) - Compressor #5
AO 34 30040
AO_01[39] WR_AO_01[39]
DTC6 Compressor State
Compressor State (see Details Page for State
Enumeration) - Compressor #6
AO 35 30041
AO_01[40] WR_AO_01[40]
Available Capacity Chiller Available Capacity in %
AO 36 30042
AO_01[41] WR_AO_01[41]
Spare Unscaled Data 3
AO 37 30043
AO_01[42] WR_AO_01[42]
DTC1 Discharge Pressure
Discharge Pressure (Integer Value with 1 implied
decimal) - Compressor #1
AO 38 30044
AO_01_SC[43] WR_AO_01_SC[43]
DTC2 Discharge Pressure
Discharge Pressure (Integer Value with 1 implied
decimal) - Compressor #2
AO 39 30045
AO_01_SC[44] WR_AO_01_SC[44]
DTC3 Discharge Pressure
Discharge Pressure (Integer Value with 1 implied
decimal) - Compressor #3
AO 40 30046
AO_01_SC[45] WR_AO_01_SC[45]
DTC4 Discharge Pressure
Discharge Pressure (Integer Value with 1 implied
decimal) - Compressor #4
AO 41 30047
AO_01_SC[46] WR_AO_01_SC[46]
DTC5 Discharge Pressure
Discharge Pressure (Integer Value with 1 implied
decimal) - Compressor #5
AO 42 30048
AO_01_SC[47] WR_AO_01_SC[47]
