23 69-1836—02
Limited 5-year warranty
Some states do not allow limitations on how long an implied limited warranty lasts or do not al-
low the exclusion or limitation of incidental or consequential damages, so the above limitation or
exclusionmaynotapplytoyou.Thislimitedwarrantygivesyouspeciclegalrights,andyoumay
also have other rights which vary from state to state.
Parts will be provided by our factory organization through an authorized service organization in
your area listed in the yellow pages. If you wish further help or information concerning this limited
warranty, contact:
Residential Systems
6200 Troup Highway
Tyler, TX 75707
Attention: Consumer Relations
Or visit our website: www.trane.com/residential
TW-1019-3308

Trane TCONT602AF22MA Specifications

Temperature Ranges

heat temperature range	40° to 90°F (4.5° to 32°C)
cool temperature range	60° to 99°F (16° to 37°C)
operating ambient temperature	32° to 120°F (0° to 48.9°C)

Humidity

operating relative humidity	5% to 90% (non-condensing)

Electrical Ratings

W (O) heating voltage	20-30 Vac
W (O) heating current	0.02-1.0 A
W1 W2 heating voltage	20-30 Vac
W1 W2 heating current	0.02-0.5 A
Y cooling voltage	20-30 Vac
Y cooling current	0.02-1.0 A
Y2 cooling voltage	20-30 Vac
Y2 cooling current	0.02-1.0 A
G fan voltage	20-30 Vac
G fan current	0.02-0.5 A
X2 emergency heat voltage	20-30 Vac
X2 emergency heat current	0.02-1.0 A
F heat pump reset voltage	20-30 Vac
F heat pump reset current	0.02-0.5 A

Weight and Dimensions

height	3-9/16” (91 mm)
width	5-13/16” (147 mm)
depth	1-1/2” (38 mm)
