Trane TCONT602AF22MA User Manual

1 69-1836—02
Table of Contents
About your new Comfort Control
Control features ......................................... 2
Programming at a glance .......................... 3
Quick reference to controls ....................... 4
Quick reference to display ........................5
Programming & Operation
Set time and day ........................................6
Select fan setting (auto/on) ....................... 7
Select system setting (heat/cool).............. 8
Using program schedules ......................... 9
Program schedule overrides ................... 12
Auto-changeover (heat/cool) ................... 14
Compressor protection ............................15
Adaptive Intelligent Recovery
TM
............... 16
Appendices
Battery replacement ................................ 17
In case of difficulty................................... 18
Customer assistance ............................... 20
Accessories/replacement parts .............. 20
Limited Warranty ...................................... 21
This Comfort Control is ready to go!
Your new Comfort Control is pre-
programmed and ready to go.
See page 3 to check settings.
CAUTION: EQUIPMENT DAMAGE
HAZARD. To prevent possible
compressor damage, do not operate
cooling system when outdoor
temperature is below 50°F (10°C).

Trane TCONT602AF22MA Specifications

Temperature Ranges

heat temperature range	40° to 90°F (4.5° to 32°C)
cool temperature range	60° to 99°F (16° to 37°C)
operating ambient temperature	32° to 120°F (0° to 48.9°C)

Humidity

operating relative humidity	5% to 90% (non-condensing)

Electrical Ratings

W (O) heating voltage	20-30 Vac
W (O) heating current	0.02-1.0 A
W1 W2 heating voltage	20-30 Vac
W1 W2 heating current	0.02-0.5 A
Y cooling voltage	20-30 Vac
Y cooling current	0.02-1.0 A
Y2 cooling voltage	20-30 Vac
Y2 cooling current	0.02-1.0 A
G fan voltage	20-30 Vac
G fan current	0.02-0.5 A
X2 emergency heat voltage	20-30 Vac
X2 emergency heat current	0.02-1.0 A
F heat pump reset voltage	20-30 Vac
F heat pump reset current	0.02-0.5 A

Weight and Dimensions

height	3-9/16” (91 mm)
width	5-13/16” (147 mm)
depth	1-1/2” (38 mm)
