Trane TEM4 Series User Manual

10
18-GF75D1-1C-EN
TEM4B0C37M31SA, TEM4A0C43M41SB
EXTERNAL STATIC
(in w.g)
AIRFLOW
Speed Taps: 208 – 230 VOLTS
High Med-High
Med † Med-Low Low
0.1 1492 1418
1302 1268 1140
0.2 1460 1385
1266 1230 1096
0.3 1426 1349
1228 1190 1050
0.4 1390 1311
1187 1147 1002
0.5 1352 1271
1144 1101 952
0.6 1311 1229
1099 1053 899
0.7 1269 1184
1051 1003 845
• In downflow applications, airflow must not exceed 1600 cfm due to condensate blowoff.
• Low = Tap 1, Med-Low = Tap 2, Med = Tap 3, Med-High= Tap 4, High = Tap 5
TEM4A0C48S41SC
EXTERNAL STATIC
(in w.g)
AIRFLOW
Speed Taps: 208–230 VOLTS
High
Med Low †
0.1 1784 1698 1634
0.2 1748 1662 1595
0.3 1715 1627 1559
0.4 1682 1591 1521
0.5 1650 1558 1488
0.6 1618 1525 1455
0.7 1499 1494 1422
• In downflow applications, airflow must not exceed 1600 cfm due to condensate blowoff.
• Low = Taps 1–3, Med = Tap 4, High = Tap 5
TEM4A0C49M41SB, TEM4B0C60S51SA
EXTERNAL STATIC
(in w.g)
AIRFLOW
Speed Taps: 208 – 230 VOLTS
High Med-High
Med † Med-Low Low
0.1 2040 1874 1658 1512 1373
0.2 2008 1846 1622 1476 1333
0.3 1975 1816 1585 1438 1289
0.4 1942 1785 1546 1395 1240
0.5 1909 1751 1506 1349 1187
0.6 1875 1716 1463 1300 1129
0.7 1841 1678 1418 1246 1067
• In downflow applications, airflow must not exceed 1800 cfm due to condensate blowoff.
• Low = Tap 1, Med-Low = Tap 2, Med = Tap 3, Med-High= Tap 4, High = Tap 5
Notes:
• Values are with wet coil, no filter, and no heaters
• CFM Correction for dry coil = Add 3%
• † = Factory Setting
