Trane TEM4 Series User Manual

12
18-GF75D1-1C-EN
TEM4A0C42S41SC
BAYHTR1517BRK with
single circuit power
source kit
BAYSPEKT201A
1/1
14.4 49100 60.0 83 90 10.8 36900 51.9 73 80
BAYHTR1523BRK with
single circuit power
source kit
BAYSPEKT201A
1/1
19.2 65500 80.0 108 110 14.4 49100 69.2 94 100
(a)
MCA and MOP for circuit 1 contains the motor amps.
TEM4B0C37M31SA, TEM4A0C43M41SB
Heater Model No.
No. of
Circuits/
Phases
240 Volt 208 Volt
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
kW BTUH kW BTUH
No Heater 4.1 * 5 15 4.1 * 5 15
BAYHTR1504BRK
BAYHTR1504LUG
1/1
3.8 13100 16.0 25 25 2.9 9800 13.8 22 25
BAYHTR1505BRK
BAYHTR1505LUG
1/1
4.8 16400 20.0 30 30 3.6 12300 17.3 27 30
BAYHTR1508BRK
BAYHTR1508LUG
1/1
7.7 26200 32.0 45 45 5.8 19700 27.7 40 40
BAYHTR1510BRK
BAYHTR1510LUG
1/1
9.6 32800 40.0 55 60 7.2 24600 34.6 48 50
BAYHTR1517BRK-
Circuit 1
(a)
2/1
9.6 32800 40.0 55 60 7.2 24600 34.6 48 50
BAYHTR1517BRK-
Circuit 2
4.8 16400 20.0 25 25 3.6 12300 17.3 22 25
BAYHTR1523BRK-
Circuit 1
(a)
2/1
9.6 32800 40.0 55 60 7.2 24600 34.6 48 50
BAYHTR1523BRK-
Circuit 2
9.6 32800 40.0 50 50 7.2 24600 34.6 43 45
BAYHTR3510LUG
1/3
9.6 32800 23.1 33 35 7.2 24600 20.0 30 30
BAYHTR3517LUG
1/3
14.4 49100 34.6 48 50 10.8 36900 30.0 42 45
BAYHTR1517BRK with
single circuit power
source kit
BAYSPEKT201A
1/1
14.4 49100 60.0 83 90 10.8 36900 51.9 73 80
BAYHTR1523BRK with
single circuit power
source kit
BAYSPEKT201A
1/1
19.2 65500 80.0 108 110 14.4 49100 69.2 94 100
(a)
MCA and MOP for circuit 1 contains the motor amps.
TEM4A0C48S41SC
Heater Model No.
No. of
Circuits/
Phases
240 Volt 208 Volt
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
kW BTUH kW BTUH
No Heater 6.0 * 8 15 6.0 * 8 15
BAYHTR1504BRK
BAYHTR1504LUG
1/1
3.84 13100 16.0 28 30 2.88 9800 13.8 25 25
BAYHTR1505BRK
BAYHTR1505LUG
1/1
4.8 16400 20.0 33 35 3.6 12300 17.3 29 30
BAYHTR1508BRK
BAYHTR1508LUG
1/1
7.68 26200 32.0 48 50 5.76 19700 27.7 42 45
BAYHTR1510BRK
BAYHTR1510LUG
1/1
9.6 32800 40.0 58 60 7.2 24600 34.6 51 60
BAYHTR1517BRK-
Circuit 1
(a)
2/1
9.6 32800 40.0 58 60 7.2 24600 34.6 51 60
BAYHTR1517BRK-
Circuit 2
4.8 16400 20.0 25 25 3.6 12300 17.3 22 25
BAYHTR1523BRK-
Circuit 1
(a)
2/1
9.6 32800 40.0 58 60 7.2 24600 34.6 51 60
BAYHTR1523BRK-
Circuit 2
9.6 32800 40.0 50 50 7.2 24600 34.6 43 45
PPeerrffoorrmmaannccee aanndd EElleeccttrriiccaall DDaattaa

Trane TEM4 Series Specifications

General

Type	Air Handler
Series	TEM4
Refrigerant	R-410A
Motor Type	PSC or ECM
Cabinet Type	Upflow, Downflow, Horizontal
Dimensions	Varies by model
Weight	Varies by model
