20
18-GF75D1-1C-EN
Figure 10. TEM4B0B24M21SAA
Top Cap
Sna
p
Tab
Fe
ature
Snap Tab
Feature
Top Cap
Rep
lace 2 screws
and
water diverter
br
acket
Remove 2 screws
and water diverter
bracket
Figure 11. TEM4A0B31M31SBB
Top Cap
Snap Tab
Feature
Snap Tab
Feature
Top Cap
Replace 2 screws
and water diverter
bracket
Remove 2 screws
and water diverter
bracket
CCooiill CCoonnvveerrssiioonn IInnssttrruuccttiioonnss
