18-GF75D1-1C-EN
21
Figure 12. TEM4B0C37M31SAA, TEM4A0C43M41SBA
Snap Tab
Feature
Top Baffle
Assembly
Replace 2 screws
and water diverter
bracket
Remove 2 screws
and water diverter
bracket
Snap Tab
Feature
Top Baffle
Assembly
Figure 13. TEM4A0C42S41SCA, TEM4A0C48S41SCA
CCooiill CCoonnvveerrssiioonn IInnssttrruuccttiioonnss
