Tracer MP580/581 bindings
CNT-SVP01C-EN 111
nviEnergyKwh SNVT_elec_kwh Analog Bind to this network variable input to communicate
electrical energy usage in kilo Watt-hours to the
device.The valid range is from 0 kWh to 65,535 kWh
with a resolution of 1 kWh.
nviEnergyWhr SNVT_elec_whr_f Analog Bind to this network variable input to communicate
electrical energy usage in Watt-hours to the device.
The valid range of this floating point value is from
0 Wh to 1E38 Wh.
nviFlow01 …
nviFlow05
SNVT_flow Analog Bind to these five network variable inputs to commu-
nicate flow rate in liters per second to the device. The
valid range is from 0 L/s to 65,534 L/s with a resolu-
tion of 1 L/s.
nviIllum01 …
nviIllum02
SNVT_lux Analog Bind to these two network variable inputs to commu-
nicate illuminations in lux to the device. The valid
range is from 0 lux to 65,535 lux with a resolution of
1lux.
nviHeatCool01 …
nviHeatCool20
SNVT_hvac_mode Enumerated Bind to these 20 network variable inputs to communi-
cate the application (heat/cool) modes of other
devices to the device.
nviOccManCmd SNVT_occupancy Enumerated Bind to this network variable input to communicate
occupancy overrides to the device.
nviOccSchedule SNVT_tod_event Enumerated Bind to this network variable input to communicate
scheduled occupancy to the device.
nviDeviceOccup01 …
nviDeviceOccup20
SNVT_occupancy Enumerated Bind to these 20 network variable inputs to communi-
cate the occupancy modes of other devices to the
device.
nviPercent01 …
nviPercent20
SNVT_lev_percent Analog Bind to these 20 network variable inputs to communi-
cate levels in percent to the device. The valid range is
from –163.84% to 163.83% with a resolution of
0.005%.
nviPower SNVT_power Analog Bind to this network variable input to communicate a
power in Watts to the device. The valid range is from
0 W to 6,553.5 W with a resolution of 0.1 W.
nviPower_f SNVT_power_f Analog Bind to this network variable input to communicate a
power in Watts to the device. The valid range of this
floating point value is from –1E38 W to 1E38 W.
nviPower_kilo SNVT_power_kilo Analog Bind to this network variable input to communicate a
power in kilo Watts to the device. The valid range is
from 0 kW to 6,553.5 kW with a resolution of 0.1 kW.
nviPressure01 …
nviPressure05
SNVT_press_p Analog Bind to these five network variable inputs to commu-
nicate pressures in Pascals to the device. The valid
range is from –32,768 Pa to 32,766 Pa with a resolu-
tion of 1 Pa.
Table 8. Tracer MP580/581 generic network variable inputs (Continued)
Variable name SNVT Data type Description
