Chapter 6 Graphical programming overview
72 CNT-SVP01C-EN
Figure 43. TGP editor running in Rover service tool
TGP editor
The TGP editor screen includes the design space, output display, blocks,
menu bar, toolbars, and shortcut menus.
Design space
The design space is the area in which you can draw graphical programs.
Output display
The output display is the area in which results from building a graphical
program appear.
To show or hide the output display:
Design
space
Menu bar
Toolbars
Output
window
Title bar
Splitter bar
