Trane Tracer UC400 User Manual

BAS-SVX48H-EN
7
Specifications and Dimensions
Table 1. UC400/UC400–B Specifications
Storage
Temperature:
–48°F to 203°F (–44°C to 95°C)
Relative Humidity: Between 5% and 95% (non-condensing)
Operating
Temperature: –40°F to 158°F (–40°C to 70°C)
Humidity: Between 5% and 95% (non-condensing)
Input Power: 20.4–27.6 Vac (24, ±15% nominal), 50Hz to 60Hz, 24 VA
(24 VA plus binary output loads for a maximum of 12 VA for each binary output)
Mounting Weight of
Controller:
Supporting mounting surface: must be 0.80 lb. (.364 kg)
Environmental Rating
(Enclosure):
NEMA 1
Altitude: 6,500 ft. maximum (1,981 m)
Installation: U.L. 840: Category 3
Pollution: U.L. 840: Degree 2
Housing Material:
(a)
Polycarbonate/ABS Blend
UV protected
U.L. 94-5VA flammability rating
Mounting: UC400: Mounts on EN 50 022 - 35 X 15 DIN rail.
UC400–B: Pre-mounted.
Agency Listing
UL916 PAZX, Open Energy Management Equipment
UL94-5V, Flammability
CE Marked
FCC Part 15, Subpart B, Class B Limit
AS/NZS CISPR 22:2006
VCCI V-3/2008.04
ICES-003, Issue 4:2004
Communications BACnet
®
MS/TP, supports BACnet Protocol ASHRAE 135-2004 and Meets BACnet Testing Laboratory (BTL) as an Application
Specific Controller (ASC) Profile Device
(a)
Not applicable for the UC400-B model.

Trane Tracer UC400 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°F to 158°F (-40°C to 70°C)
Enclosure Rating	IP20
Controller Type	Programmable
Communication Protocol	BACnet MS/TP
Power Supply	24 VAC
Power Consumption	10 VA
Humidity Range	5% to 90% RH non-condensing
Supply Voltage	24 VAC/VDC
