Trane Tracker Version 12 User Manual

Overview
BMTK-SVN01D-EN 3
®
Figure 3. Example building automation system (water-source heat pump) on a network
Voyager constant
volume rooftop
Precedent rooftop
with ReliaTel controls
Priority shutdown
contact input
Outdoor air
temperature sensor input
Utility pulse meter input
Analog inputs
Binary outputs
Tracer ZN517
unitary controller
Binary inputs
Interconnecting wiring
(Comm5 link): single, twisted
pair, shielded wire for two-
way communication.
Universal inputs
Binary outputs
Alarm relay output
Tracker
controller
Generic rooftop
Tracer MP503
I/O module
Analog inputs
Binary outputs
Binary inputs
Tracer ZN510, ZN511, or
ZN524 controller
Tracer loop controller
(for water-source
pump)heat
Tracer
LCI-V
Tracer
LCI-R
Direct, dial-in (modem),
or Ethernet connection
