Controller components
BMTK-SVN01D-EN 7
Display module
The display module (Figure 7) is a housing that contains a printed circuit
board, liquid crystal display (LCD) touch screen, and an alarm LED. The
printed circuit board supports the LCD touch screen and the alarm LED.
The touch screen provides the operator access to the user interface
program.
The display module can be “hot swapped:” it can be removed and installed
without removing power from the main module. When the display module
is installed onto a powered main module, it receives power and begins to
operate automatically.
Figure 7. Display module
LCD touch screen
Alarm LED
