Wire 24 Vac power
BMTK-SVN01D-EN 25
®
Wire 24 Vac power
After the termination module is mounted in the selected location, wire
24 Vac power to the termination board. Table 5 shows the specifications
for power wiring.
IMPORTANT
The 24 Vac wire conduit may not contain input/output or communica-
tion wires. Failure to comply may cause the Tracker controller to mal-
function due to electrical noise.
1. Route input wires into the termination module through the conduit
box or any of the conduit access openings designated for input and
communication wiring (Figure 12 on page 19).
2. Wire the two 24 Vac power input wires and the ground wire to the
controller 24 VAC terminals (Figure 14 on page 24).
Table 5. Power wiring specifications
24 Vac power
terminals
Description Wire specifications
24 Vac
TB1-1, TB1-2,
Earth ground TB1-3
Power input
24 Vac nominal (19–30 Vac), 50/60 Hz,
1 phase 40 VA minimum, class 2
transformer required
Trane recommends 18 AWG (1.02 mm
2
) wire and
metal conduit.
Low voltage (24 Vac) wire must comply with
National Electrical Code (NEC) and federal, state,
and local electrical codes.
