Trane TZON1050AC52ZC User Manual

Installation Guide
28 18-HD80D1-6E-EN
9.5 System Report
The System Report Screen provides technicians with
important system operational data in one, concise screen.
The data is provided in real-time and updates as the data
changes. The tables below show the information available
for zoned and non-zoned systems.
9.6 Restore Factory Defaults
This feature will delete all saved settings, both user and
installer, and restore the 1050 Control to its factory default
settings. Z-Wave™ settings will not be cleared.
SYSTEM REPORT SCREEN SYSTEM REPORT SCREEN - ADDITIONS FOR ZONING
FIELD NAME DESCRIPTION FIELD NAME DESCRIPTION
System Name Name given to this 1050 Control. Zone Name Displays enabled zones
Operation Status Current mode of operation Mode Indicates current mode per zone
Operation Stage Current stage of operation Size Indicates air flow capacity per zone
*Req Capacity Amount of capacity being requested Temp Current indoor temperature per zone
*Delv Comp Spd Percentage of compressor speed currently
operating
Cool Current cooling set point per zone
Load Value Numerical value used to determine how
much capacity is required to meet set point.
For more information see 6.2 Load Value.
Heat Current heating set point per zone
Air Flow Current percent of air flow being delivered
(this value is only available for indoor units
with variable speed blowers operating in
cooling or compressor heating operation)
Load Current load value per zone
**Excess Air Amount of excess air currently calculated RH Current indoor RH per zone
ODT Current outdoor temperature (requires
an outdoor temperature sensor to be
connected and enabled)
DMP Current damper position per zone
**Static PSI Current static pressure being measured Sensor Indicates the indoor temperature sensor
type per zone
**Return Air Temp Current temperature of return air * Only applicable for systems with a VSPD outdoor unit
**Only applicable for zoned systems
**Discharge Air Temp Current temperature of supply air
Humidifier Indicates current status of humidifier, if
installed
Dehumidifier Indicates current status of dehumidifier, if
installed
Ventilation Indicates current status of ventilation
system, if installed
