Startup
UNT-SVX07J-EN 11 3
Zone Sensor
The controller accepts the following zone sensor module
inputs:
• Space temperature measurement (10kΩ thermistor)
• Local setpoint (either internal or external on the zone
sensor module)
• Fan switch
• Timed override (On) and Cancel timed override
• Communication jack
Space Temperature Measurement
Trane zone sensors use a 10kΩ thermistor to measure the
space temperature. Typically, zone sensors are wall-
mounted in the room and include a space temperature
thermistor. As an option, the zone sensor can be unit-
mounted with a separate space temperature thermistor
located in the unit’s return air stream. If both a hard-wired
and communicated space temperature value exist, the
controller ignores the hard-wired space temperature input
and uses the communicated value.
External Setpoint Adjustment
Zone sensors with an external setpoint adjustment (1kΩ)
provide the controller with a local setpoint (50°F to 85°F or
10°C to 29.4°C). The external setpoint is exposed on the
zone sensor’s front cover.
When the hard-wired setpoint adjustment is used to
determine the setpoints, all unit setpoints are calculated
based on the hard-wired setpoint value, the configured
setpoints, and the active mode of the controller. The hard-
wired setpoint is used with the controller’s occupancy
mode (occupied, occupied standby, or unoccupied), the
heating or cooling mode, the temperature deadband
values, and the heating and cooling setpoints (high and
low limits) to determine the controller’s active setpoint.
When a building automation system or other controller
communicates a setpoint to the controller, the controller
ignores the hard-wired setpoint input and uses the
communicated value. The exception is the unoccupied
Table 57. Zone Sensor Thermistor Curve (Resistance in Ohms)
°C °F R °C °F R °C °F R °C °F R
0 32 32885 25 77 10004 50 122 3759 75 167 1484
1 33.8 31238 26 78.8 9557 1 123.8 3597 76 168.8 1436
2 35.6 29684 27 80.6 9135 52 125.6 3445 77 170.6 1389
3 37.4 28216 28 82.4 8737 53 127.4 3301 78 172.4 1345
4 39.2 26830 29 84.2 8362 54 129.2 3165 79 174.2 1302
5 41 25520 30 86 8007 55 131 3037 80 176 1260
6 42.8 24282 31 87.8 7672 56 132.8 2915 81 177.8 1220
7 44.6 23112 32 89.6 7355 57 134.6 2800 82 179.6 1182
8 46.4 22005 33 91.4 7056 58 136.4 2691 83 181.4 1145
9 48.2 20957 34 93.2 6772 59 138.2 2588 84 183.2 1109
10 50 19966 35 95 6503 60 140 2490 85 185 1074
11 51.8 19028 36 96.8 6248 61 141.8 2397 86 186.8 1041
12 53.6 18139 37 98.6 6006 62 143.6 2309 87 188.6 1009
13 55.4 17297 38 100.4 5777 63 145.4 2225 88 190.4 978
14 57.2 16499 39 102.2 5559 64 147.2 2145 89 192.2 948
15 59 15743 40 104 5352 65 149 2070 90 194 920
16 60.8 15025 41 105.8 5156 66 150.8 1998 91 195.8 892
17 62.6 14345 42 107.6 4969 67 152.6 1929 92 197.6 865
18 64.4 13700 43 109.4 4791 68 154.4 1864 93 199.4 839
19 66.2 13087 44 111.2 4621 69 156.2 1802 94 201.2 814
20 68 12505 45 113 4460 70 158 1742 95 203 790
21 69.8 11953 46 114.8 4306 71 159.8 1686 96 204.8 767
22 71.6 11428 47 116.6 4160 72 161.6 1632 97 206.6 744
23 73.4 10929 48 118.4 4020 73 163.4 1580 98 208.4 722
24 75.2 10455 49 120.2 3886 74 165.2 1531 99 210.2 701
