Trane UniTrane User Manual

Dimensions and Weights
28 UNT-SVX07J-EN
Model H Vertical Recessed
Figure 11. Model H Vertical Recessed
Top View
Front View
RH Piping
Front View
LH Piping
Side
View
5 1/2 in.
C
1 3/4 in. 1 3/4 in.
(4) 5/8 in. dia keyslot
hanger holes
3 7/16 in.
5 5/16 in.
Top outlet
duct collar (optional)
6 5/8 in.
Power
wiring
bottom
only
7/8 in. KO
1 3/32 in. KO
2 5/16 in.
4 9/16 in.
1 in.
D
1 in.
3/4 in.
1 3/4 in.
3/4 in.
1 3/4 in.
6 5/8 in.
7/8 in. KO
control wiring
Front outlet louvers
Control
box
Optional
disconnect
switch
7 5/8 in.
4 7/16 in.
6 15/16 in.
Front inlet louvers
6 7/16 in.
A
H Wall opening
F
Front
panel
J
Wall
opening
15 1/2 in.
7 in.
G
B
(4) 5/8 in. dia keyslot
hanger holes
1 in.
4 15/16 in.
7 in.
E Front panel
Coil connections
Auxiliary
drain pan
1 1/8 in.
1 in.
Wall opening
Power wiring 7/8 in.
or 1 3/32 in. KOs
Front
control
access
(optional)
15 3/8 in.
4 15/16 in.
Control
box
5/8 in.
1 in. duct
collar
25 1/4 in.
10 1/16 in.
1 9/16 in.
5 7/16 in.
Filters
Main drain connection
for 7/8 in. OD copper
tube and clamp
Secondary
drain connection
for 3/8 in. ID tube
9 3/4 in.
1 in.
