Dimensions and Weights
30 UNT-SVX07J-EN
Model J Vertical Slope Top Cabinet
Figure 12. Model J Vertical Slope Top
Top V iew
6 5/8 in.
1 1/16 in.
6 1/2 in.
(4) Unit leveling devices
(optional)
6 5/8 in.
2 7/8 in.
1 3/8 in. KO
6 1/4 in.
Power
wiring
bottom
only
7/8 in. KO
1 3/32 in. KO
Unit control
top
C
D
Top outlet
Quadrifuser or bar grille
C
Front View
LH Piping
Coil connections
Auxiliary
drain pan
1 1/8 in.
Filters
Control
box
Aux
box
Power wiring 7/8 in.
or 1 3/32 in. KOs
10 in.
Side
View
Air
flow
24 7/8 in.
Secondary drain
connection
for 3/8 in ID tube
Main drain connection
for 7/8 in. OD copper
tube and clamp
5 7/16 in.
1 9/16 in.
10 in.
Bottom View
Back
Back
Front
Front
Power
wiring
bottom
and side
7/8 in. KO
6 1/2 in.
1 in.
2 5/8 in.
DETAIL A
Electric heat only
DETAIL B
Non-electric heat only
Front View
RH Piping
6 in. B
6 in.
Auxiliary
control box
(electric heat only)
5 1/4 in.
6 11/16 in.
Control
box
Front inlet
open or bar grille
7 in.
E
A
7 in.
8 in.
F Optional extended end pocket
(4) 5/8 in. dia keyslot
hanger holes
(2) 5/8 in. bolt holes
15 1/2 in.
6 15/16 in.
5 1/16 in.
1 5/8 in.
Front outlet louvers
(optional)
8 in.
See Detail A
and Detail B
for field power
connections
G Optional double extended end pocket
Junction box
(non-electric heat only)
