Trane UniTrane User Manual

Dimensions and Weights
34 UNT-SVX07J-EN
Model L Low Vertical Cabinet
Figure 14. Model L Low vertical cabinet
11 5/8 in. HR
10 3/4 in. HS
9 5/8 in. CR
8 5/16 in. CS
HR
HS
CS
CR
9 3/16 in.
HR
6 7/8 in.
HS
9 3/16 in.
CS
8 11/16 in.
CR
Right hand coil connections shown.
Left hand connection locations
are mirror image.
HR-heating coil return
HS-heating coil supply
CR-cooling coil return
CS-cooling coil supply
Main drain connection for
7/8 in. OD copper tube and clamp
Air
flow
14 9/16 in.
1 15/16 in.
2 in.
14 1/2 in.
1 5/16 in.
Filters
9 11/16 in.
Power
wiring
bottom
only
7/8 in. KO
6 7/8 in.
1 1/8 in.
Coil connections
Auxiliary
drain pan
Control
box
Front View
LH Piping
Front View
RH Piping
7/8 in.
B
7/8 in.
7/8 in. KO Control wiring
1 13/16 in.
1 13/16 in.
(2) 5/8 in dia Keyslot
hanger holes
Control
box
Main power
access
Bottom of
control box
2 11/16 in.
Front inlet bar grille
3 1/4 in.
6 7/16 in.
11 5/16 in.
E
A
11 5/16 in.
13 3/16 in.
Top V iew
(2) 5/8 in. dia Keyslot
hanger holes
10 15/16 in.
(4) Unit leveling devixces
(optional)
10 15/16 in.
4 7/16 in.
8 1/2 in.
Unit control
top
C CD
Top outlet quadrifuser
or bar grille
Side View
