Dimensions and Weights
UNT-SVX07J-EN 39
Table 14. Model N Inverted vertical recessed unit dimensions (in.) and weights (lb)
Unit Size 02–03 04 06 08 10–12
A 27 7/8 32 7/8 42 3/8 50 7/8 69 7/8
B 21 5/16 26 5/16 35 13/16 44 5/16 63 5/16
C 22 13/16 27 13/16 37 5/16 45 13/16 64 13/16
D 2 3/8 2 3/8 2 3/8 4 1/8 4 1/8
E 47 51 63 65 1/2 89 1/2
F 30 30 30 33 1/2 33 1/2
G 26 1/2 26 1/2 26 1/2 27 1/2 27 1/2
H 42 48” 57 63 87
Operating Weight 78 88 128 139 253
Shipping Weight 68 78 118 129 243
Notes: Coil connections are always on the drain pan side and opposite the control box. Coil connections are 5/8-in. O.D. sweat. See the Coil Connections
section for locations. All duct collar dimensions are to the outside of the collar. See the Fresh Air Openings Locations section for dimensions.
