Trane UniTrane User Manual

Installation - Electrical
UNT-SVX07J-EN 63
Table 34. Force-Flo single stage, low kW electric heat
Unit
Size
Voltage
#
Wires
kW
amps/
ph
kW
amps/
ph
kW
amps/
ph
2
208/60/1 2 0.8 3.7 1.5 7.3
240/60/1 2 1.0 4.2 2.0 8.4
277/60/1 2 1.0 3.7 2.0 7.3
220-240/50/1 2 1.0 4.2 2.0 8.4
3
208/60/1 2 2.3 10.9
240/60/1 2 3.0 12.5
277/60/1 2 3.0 10.9
208/60/3 3 2.3 6.3
240/60/3 3 3.0 7.3
480/60/3 4 3.0 3.7
220-240/50/1 2 3.0 12.5
220-240/50/3 3 3.0 7.3
380-415/50/3 4 3.0 4.2
4
208/60/1 2 2.3 10.9
240/60/1 2 3.0 12.5
277/60/1 2 3.0 10.9
208/60/3 3 2.3 6.3
240/60/3 3 3.0 7.3
480/60/3 4 3.0 3.7
220-240/50/1 2 3.0 12.5
220-240/50/3 3 3.0 7.3
380-415/50/3 4 3.0 4.2
6
208/60/1 2 2.3 10.9 3.3 15.9
240/60/1 2 3.0 12.5 4.5 18.8
277/60/1 2 3.0 10.9 4.5 16.3
208/60/3 3 2.3 6.3 3.3 9.2
240/60/3 3 3.0 7.3 4.5 10.9
480/60/3 4 3.0 3.7 4.5 5.5
220-240/50/1 2 3.0 12.5 4.5 18.8
220-240/50/3 3 3.0 7.3 4.5 10.9
380-415/50/3 4 3.0 4.2 4.5 6.3
8
208/60/1 2 2.3 10.9 3.3 15.9 5 21.7
240/60/1 2 3.0 12.5 4.5 18.8 6 25.0
277/60/1 2 3.0 10.9 4.5 16.3 6 21.7
208/60/3 3 2.3 6.3 3.3 9.2 5 12.5
240/60/3 3 3.0 7.3 4.5 10.9 6 14.5
480/60/3 4 3.0 3.7 4.5 5.5 6 7.3
220-240/50/1 2 3.0 12.5 4.5 18.8 6 25.0
220-240/50/3 3 3.0 7.3 4.5 10.9 6 14.5
380-415/50/3 4 3.0 4.2 4.5 6.3 6 8.4
Unit
Size
Voltage
#
Wires
kW
amps/
ph
kW
amps/
ph
kW
amps/
ph
10
208/60/1 2 2.3 10.9 3.3 15.9 6 27.5
240/60/1 2 3.0 12.5 4.5 18.8 8 31.3
277/60/1 2 3.0 10.9 4.5 16.3 8 27.1
208/60/3 3 2.3 6.3 3.3 9.2 6 15.9
240/60/3 3 3.0 7.3 4.5 10.9 8 18.1
480/60/3 4 3.0 3.7 4.5 5.5 8 9.1
220-240/50/1 2 3.0 12.5 4.5 18.8 8 31.3
220-240/50/3 3 3.0 7.3 4.5 10.9 8 18.1
380-415/50/3 4 3.0 4.2 4.5 6.3 8 10.5
12
208/60/1 2 2.3 10.9 4.5 21.9 7 31.8
240/60/1 2 3.0 12.5 6.0 25.2 9 37.5
277/60/1 2 3.0 10.9 6.0 21.9 9 32.5
208/60/3 3 2.3 6.3 4.5 12.5 7 18.4
240/60/3 3 3.0 7.3 6.0 14.5 9 21.7
480/60/3 4 3.0 3.7 6.0 7.3 9 10.9
220-240/50/1 2 3.0 12.5 6.0 25.2 9 37.5
220-240/50/3 3 3.0 7.3 6.0 14.5 9 21.7
380-415/50/3 4 3.0 4.2 6.0 8.4 9 12.6
Note: All data based on individual units.
Table 34. Force-Flo single stage, low kW electric heat
