Trane VAV-UCM 4.2 - Setting the Address, Mounting, Wiring, and Associating the Receiver and Sensor

22 VAV-SVX01C-EN
Wireless Zone Sensor
Setting the Address, Mounting, Wiring, and Associating the Receiver
and Sensor
The following procedure list shows the recommended order for installation:
• Choosing a location for mounting the sensor
• Setting the rotary address switches on the receiver and on the sensor
• Replacing and securing the receiver cover
• Powering the sensor and associating the sensor to the receiver
• Applying power to the receiver
• Testing signal and battery strength
• Disassociation
Figure 7. Mounting hole dimensions for sensor
3.27 in (8.30 cm)
2.36 in (6.00 cm)
1.34 in (3.41 cm)
Note: The dimensions are the
same for both the sensor
and the receiver.
